trusTec Motor - 1/3HP 6P Condenser Fan Motor YDK-250-6A19
| Product Name | Condenser Fan Motor | Voltage | 208V-230V |
|---|---|---|---|
| Frequency | 60Hz | Output Power | 1/3HP |
| Pole | 6P | AMPS | 1.8A |
| Speed | 1075RPM | Capacitor | 10μF/370V |
| Insulation Class | Class B |
Power Factor |
0.9 |
| Other protection | THERMALLY PROTECTED | ||
Ralated Outline
Key Parameters
| Model |
Power /W |
Frequency /Hz |
Speed /RPM |
Rated Current /A |
Voltage /V |
| YDK-250-6A14 | 1/3 HP | 60 | 1075 | 1.8 | 208-230 |
Ps:all dimension can be customized according to customer requirement.
Product features
A.High performance motor with UL, CE & ISO9001.
B.Low noise excellent quality rolling bearing because the motor use NSK.
C.Excellent design and reasonable price.
Our advantages
A.The leading HVAC supplier of Changzhou TrusTec Company Limited,we are always keep innovation mind and specialized in designing and producing air-conditioning motor,for example,condenser motor ,fan coil unit motor,outdoor unit motor and indoor unit motor.etc
B.Our main products have single and double shaft,single and three phase motors,the motor specification can be adjust according to customers requirement.
C.Our different kinds of motor have been being exported to the have been many market ,the main market such as North America, Europe and Mid-east.At the same time,we have own distributor in different market.
Our services:
A. Welcome OEM/ODM.Barrier-free communication, fast response to customer inquiry.
B. We offered all kinds of services in order to meet customer requirements.and can design customized motors for various customers to help them win with more advanced characteristics.
C.We promise that fast reply, high effiency communication with customers.
FAQ
Q:What's the condenser motor?
A:Compressor suction from the evaporator working medium low pressure steam, after pressure into the condenser, cold high pressure of the liquid condensed in the condenser, the throttle valve throttle, become low pressure liquid into the evaporator, the evaporator of heat to evaporate and become a low pressure steam, thus complete the refrigeration cycle.
Q:If products have some problem,What should do?
A:firstly,every products will be check carefully after finished,and if producthave qulity problem,we will guarantee 100% replacement service.
Q:How long the products warranty?
A:The warranty is 24 months on the production date.
