Galvanised Round Steel Wire Armour Polyethylene PE Insulation PVC Jacket For K Thermocouple
Price:
negotiable
MOQ:
100,meters
Delivery Time:
7-10 days
Brand:
OHMALLOY
Product Description
Galvanished Round Steel Wire Armour Polyethylene PE Insulation PVC Jacket For K Thermocouple
Conductor material:
| Material | Chemical composition(%) | ||||
| Ni | Al | Cr | Si | Mn | |
| Chromel | 90 | 10 | |||
| Alumel | 95 | 1-2 | 1-2 | 0.5-1.5 | |
Structure:
| Conductor size | 0.5mm |
| Inner Insulation material | Polyethylene PE |
| Insulation layer thickness | 0.2mm |
| Armour material | Galvanished round steel wire |
| Armour thickness | 0.2mm |
| Out jacket material | PVC |
| Out jacket thickness | 0.08mm |
Remarks: The size can be changed if special requirement.
The thickness of insulation also can be adjusted by special requirement. We can do insulation thickness 0.2mm to 2.5mm
Calibration tolerance:+/-1.1 ℃ or +/-0.4%
Color code: ANSI 96.1 or IEC 584-2
| Conductor | Insulator | Packing | ||||
|
sectional area mm2 |
Conductor Construction NO. x φmm |
Diameter mm |
Insulator Thick mm |
Jacket Thick mm |
Over Diameter mm |
Mt/coils |
| 0.20 | 7x0.20 | 0.61 | 0.20 | 0.15 | 1.3X2.3 | 305 |
| 19x0.12 | 0.60 | 0.20 | 0.15 | 1.3X2.3 | 305 | |
| 0.30 | 7x0.25 | 0.76 | 0.20 | 0.15 | 1.5X2.6 | 305 |
| 19x0.15 | 0.76 | 0.20 | 0.15 | 1.5X2.6 | 305 | |
| 0.50 | 7x0.3 | 0.81 | 0.20 | 0.15 | 1.8X2.7 | 305 |
| 0.81 | 0.81 | 0.20 | 0.15 | 1.8X2.7 | 305 | |
| 1.0 | 7x0.43 | 1.13 | 0.20 | 0.20 | 2.0X3.6 | 305 |
| 1.13 | 1.13 | 0.20 | 0.20 | 2.0X3.6 | 305 | |
| 1.5 | 7x0.52 | 1.38 | 0.35 | 0.20 | 2.5X4.4 | 200 |
| 1.38 | 1.38 | 0.35 | 0.20 | 2.5X4.4 | 200 | |
