Non Toxic PTFE Coated Fiberglass Fabric High Dielectric Strength
Non Toxic PTFE Coated Fiberglass Fabric High Dielectric Strength
PTFE Fiberglass Fabric
Basic fabric named fiberglass fabric use best imported Fiberglass yarn as the weaving material to plain knit or specially knit into superior fiberglass basic cloth, coat it with fine PTFE resin then make it into various PTFE fabric in different thickness and widths.
|
Color |
Thickness |
Max Width |
Weight |
Tensile Strength |
Temperature resistance |
|
brown |
0.08mm |
1.25m |
165g/sqm |
550/450N/5cm |
-140~260°C |
|
black |
0.08mm |
1.25m |
170g/sqm |
550/450N/5cm |
-140~260°C |
|
brown |
0.13mm |
1.25m |
260g/sqm |
1100/1000N/5cm |
-140~260°C |
|
black |
0.13mm |
1.25m |
275g/sqm |
1100/1000N/5cm |
-140~260°C |
|
brown |
0.15mm |
1.25m |
380g/sqm |
1200/1000N/5cm |
-140~260°C |
|
black |
0.18mm |
1.25m |
395g/sqm |
1800/1700N/5cm |
-140~260°C |
|
brown |
0.25mm |
3.20m |
490g/sqm |
2100/1800N/5cm |
-140~260°C |
PTFE Coated fiberglass fabric applications:
1) fiberglass fabric could be used as various of liners to resist high temperature, such as microwave liner, oven liner, or other liners.
2) Used as non stick liners, intermediate.
3) Used as various conveyor belts, fusing belts, sealing belts or anywhere need resisting high temperature, non stick, chemical resistance etc.
4) Used as covering or wrapping material in petroleum, chemical industries, as wrapping material, insulating material, high temperature resistance material in electrical industries, desulfurizing material in power plant etc.
Fiberglass fabric general properties:
1. Outstanding temperature resistance(from -70°C to +260°C)
2. Excellent chemical resistance
3. Superior non-stick surface, easy to clean
4. High dielectric strength
5. Dimensional stability
6. Resistance to UV, IR and HF
7. Non-toxic
