360GSM Plain weaving silicone coated fiberglass cloth For Hot Air Tunnel Curtain
360GSM Silicone Coated Fiberglass Fabric For Hot Air Tunnel Curtain
Silicone coated fiberglass fabric is a heat resistant cloth for engineering thermal insulation. It is woven from e-glass fiberglass yarns in plain weave and the woven fabric is coated with silicone on both two sides. Coating is 80g/m2 per side so the total weight is 360gsm.
Fiberglass cloth can withstand 550degree Celsius and the silicone coating is able to be used below 260℃. According to the features of silicone coated fiberglass fabric, it is always used for welding or fire blanket, fire curtains, expansion joints, removable thermal insualtion jackets.
| Item | Silicone Coated Fiberglass Fabric |
| Material | Fiber Glass |
| Weave | Plain Weave |
| Warp Density | 17.3 Ends/CM |
| Weft Density | 13 Ends/CM |
| Mass Per Unit | 360gsm |
| Thickness | 0.35mm |
| Width | 100cm |
| Temperature |
Silicone Coating below 260℃ |
Properties:
- Fire resistant
- Heat insulation
- Durable
- Corrosion resistance
- Electric insulation
Application:
- Removable thermal insulation exhaust blanket
- Fire doors, heat insulation curtains
- Fabric expansion joint
- Electrical insulation cover
- Engineering thermal insulation
- Hot air tunnel curtains
Pictures:
