Heat Reflective 0.43mm Aluminium Foil Fiberglass Cloth Fire Blanket Fabric
Heat Reflective 0.43mm Aluminium Foil Fiberglass Cloth Fire Blanket Fabric
0.43mm silver coated fabric is a basic fiber glass fabric which is laminated with aluminium foil by a high temperature adhersive. Basic cloth of 0.43mm silver coated fabric is 430gsm cloth woven in satin weave. Thicknesses of aluminium foil are 7U, 18U, 25U and 50U max. The total weight of silver coated fabric is 480g/m2. This fabric is fire resistant, chemical corrosion resistant and anti UV, anti aging, what's more, it is heat reflective and will reflect 95% heat.
Fiber glass fabric can be used from -100° F to 1022° F. And the special adhersive can be used below 300℃. Based on all these properties, this silver coated fiberglass fabric is widely used for thermal insulation in many fields.
Data Sheet
| Material | Aluminium Foil Fiberglass Fabric | ||
| Weave | 4H Satin | ||
| Yarn Type | EC9 33 2X2 | ||
| Total Weight | 480g/m2 | ||
| Thickness | 0.43 mm | ||
| Aluminium Foil | 7micron/ 18micron/ 25micron | ||
|
Tensile Strength (N/5cm) |
6000/4500 | ||
| Width | 127cm or customized | ||
| Temperature |
Basic fiberglass cloth: 550℃ Adhersive: 300℃ |
Features
- Heat reflective
- Waterproof
- Tear resistant
- Anti chemical agent
- Electrical Insulation
- Anti aging, weather
Application
- Hot work protection
- Gas, oil pipe cover
- Safety workwear
- Construction sparks protection
- Automotive heat shield
- Removable thermal insulation jacket
