Heat Reflective 0.9mm Aluminium Foil Fiberglass Silver Coated Fabric Pipe Insulation
Silver Heat Reflective 0.9mm Aluminium Foil Fiberglass Fabric Pipe Insulation
Basic cloth of this 0.9mm silver coated fabric is 850g/m2 fiberglass fabric woven in satin weave. The silver aluminium foil is laminated on the fiberglass by high temperature adhesive. The total weight is 880g/m2 and total thickness is 0.9mm. Thickness of aluminium foil can be 7u, 18u, 25u and 50u max. Basic fiberglass fabric is able to withstand 550℃ (1022℉). With properties like heat insulation, fire resistance, chemical resistance and anti UV, corrosion. The silver foil makes the fabric with a heat reflective surface which can protect it from 95% heat.
The adhesive for foil can be ued below 300℃ continuously. This silver fabric is widely used in industrial fields for fire blanket, pipe protection, safe wear, sparks splasher shield cover.
Data Sheet
| Material | Aluminium Foil Fiberglass Fabric | ||
| Weave | Satin | ||
| Thread Count | 18/13 per cm | ||
| Total Weight | 880g/m2 | ||
| Thickness | 0.9 mm | ||
| Aluminium Foil | 7micron/ 18micron/ 25micron | ||
|
Tensile Strength (N/5cm) |
8000/6000 | ||
| Width | 100cm, 125cm, 155cm | ||
| Temperature |
Fiberglass cloth: ≤550℃ Adhersive: ≤300℃ |
Features
- Heat reflective
- Waterproof
- Durable
- Chemical resistant
- Electrical Insulation
- Anti corrosion
Application
- Welding protection
- Gas, oil pipe warp material
- Safety workwear
- Construction heat insulation
- Automotive application
- Removable thermal insulation jacket
