3732 Acrylic Coated Fiberglass Fabric Yellow 530GSM Heat Resistant Blanket
3732 Acrylic Coated Fiberglass Fabric Yellow 530GSM Heat Resistant Blanket
Coated with different compound, fiber glass fabrics can be used in different fields. Basic fiberglass cloth of this yellow coated glass fabric is 430g/m2 satin woven fiber glass fabric. Acylic on two sides are 50gsm per side. Total weight of this coated cloth is 530g/m2 (about 15.6oz/sq yd). Width of coated fibreglass cloth is 1 meter standard. Rolll length is 50 meters one roll (or customized). Continuous work temperature of woven fiberglass fabric is -50 to 550℃. Acrylic coating can be used from -50 to 260℃ continuously.
Acrylic coated fiber glass fabric provides better UV, water and abrasion resistance. Also it is flexible but high strength, so it is easy to sew and fabricate into a fire blanket. Besides, this material resists chemical agents, corrosion and electrical flame. Main application of Acrylic coated fiber glass fabric is fire welding blanket.
Specification
| Item | Acrylic Coated Fiberglass Fabric |
| Total Weight | 530g/m2 |
| Thickness | 0.43mm |
| Weaving | Satin Weave |
| Yarn | G37 1/0 0.7Z, G37 1/0 0.7Z |
| Coating | Acrylic, 50/50 |
| Color | Yellow |
| Work Temperature |
Coating: -50℃ to 260℃, Fiber glass cloth ＜ 550℃ |
| Standard Width | 100cm |
| Length | 50 meters |
Features
- Flame shield
- Electrical insulation
- Anti corrosion, UV
- Durable, flexible, easy to fabricate
- Superior resistance to chemicals, moisture and heat
Application
- Smoke curtains
- Industrial welding supply
- Motor vehicle industry
- Pipe insulation
- Fire resistant blanket
- Exhaust insulation wrap
