260℃ Tear Resistance 12.6oz Aluminium Foil Coated Fiberglass Fabric
260℃ Tear Resistance 12.6oz Aluminium Foil Coated Fiberglass Fabric
Aluminium foil fiberglass fabric is made of radiant barrier aluminimun foil, adhesive and fiberglass cloth, which can reflects 90% of the infrared heat sriking its surface.
A high micron aluminium foil is laminated to continuous filament E glass cloths to prevent fray when cutting and produce a heat resistant, reflective material suitable for use as protection against radiant heat.
Aluminium Foiled Glass Fibre Cloth is available in 0.45mm or 1.5mm thickness. Applications include making protective items such as covers and gloves across different industries working at 550oC / 1020oF.
Working temperature: Aluminium foil ≤ 600℃
Fiberglass fabirc ≤ 550℃
Glue ≤ 300℃
Properties:
1.Electrical conductivity
2. Rates to 550°C
3. Anti-corrosion
4. Reduce loss of heat
5. High strength
Main Sepecification:
| Item | Weight (g/m2) |
Weight oz/yd2 |
Tensile Strength | Thickness(mm) | Weaving |
|
PCAL-8628
|
200 | 5.8 | 2025/1620 | 0.2 | Plain |
|
UPEAL-8732
|
430 | 12.6 | 6000/4500 | 0.43 | Satin |
|
UPCAL-8784
|
880 | 26 | 8000/6000 | 0.85 | Satin |
Data sheet:
|
Product name
|
Aluminium Foil Coated Fiberglass Fabric |
|
|
Aluminium Foil
|
7/18/25 Micron | |
|
Yarn Type
|
E-glass | |
|
Weight
|
430g/m2 | 12.6oz/yd2 |
|
Thickness
|
0.43mm | 0.017inch |
|
Width
|
1000/1270/1550mm | |
|
Thread Count
|
18/12.6 ±1 ends/cm |
|
|
Roll length
|
50m | |
Application:
1. Removable insulation blankets
2. Building materials
3. protective wear- gloves, covers
4. foundries
5. iron & steel industries
6. Other Fire and Smoke Control System
