Heat Reflect Aluminium Foil Silver Coated Fabric For Industry 0.85mm Thickness
0.85mm Thick Heat Reflect Aluminium Foil Coated Fiberglass Fabric For Industry
Aluminum foil fiberglass composite fabric reflects 95% or more of the radiant heat that contacts its surface. Made of a high-temperature woven fiberglass fabric adhesive with a layer of aluminium foil. It continuous working temperature is 550℃ and its short-term working temperature is 600℃.These properties make it ideal for application such as fire-proof wear, as well as use in boilers and foundries, and in vehicles,e.g.cars and motobikes.
The basic fabric weighted at 850g/m2(25oz/yd2), woven by Eight-Harness satin weave: one filling yarn flots over seven warp yarns and under one.This is a very pliable weave and is used for forming curved surface.
Constrruction: Aluminium Foiled + PE/Glue (heat resistant)+ Fiberglass Fabric
Temperature: Basic fiberglass fabric≤ 550℃
Adhesive ≤ 300℃
Aluminium Thickness:7/18/25 Micron
Weight: 850g/m2
Width: 1000/1270/1550 mm
Properties:
1. Transverse tensile
2. Smooth surface
3. Heat reflective
4. Moisture resisatnce
5. Tear resistance
6.good sealing properties
Data sheet:
|
Item
|
UPEAL-8784 | ||
|
Thread count
|
Warp |
ECG37 1/2 |
|
| Weft |
ECG37 1/2 |
||
|
Breaking Strength
|
Warp |
2600 N/5cm
|
297 lbs/inch |
| Weft |
2400 N/5cm
|
274 lbs/inch | |
|
Weight
|
850g/m2 | 25 oz/yd2 | |
|
Thickness
|
0.85mm | 0.033 inch | |
|
Width
|
0~1550mm | 0~61 inch | |
|
Surface treatment
|
Aluminium Foil | ||
|
Weave
|
Satin | ||
Application:
• HVAC Equipment
• Automotive Engine
• Removable covers and blankets
• Oil Pipe, Steam pipe
• Silencing sound insulation material
• Building reinforced materials
