Embeded 2.7'' NEC Commercial Displays NL2432HC17-01B , LCD Display Panel With Clear High Definition
Embeded 2.7'' NEC Commercial Displays NL2432HC17-01B , LCD Display Panel With Clear High Definition
NEC NL2432HC17-01B General Features:
| Panel Brand : | NEC |
| Panel Model : | NL2432HC17-01B |
| Panel Type : | a-Si TFT-LCD , Panel |
| Panel Size : | 2.7 inch |
| Resolution : | 240(RGB)×320 , QVGA |
| Display Mode : | TN, Transmissive |
| Active Area : | 41.04×54.72 mm |
| Outline : | 50.54×68.62 mm |
| Surface : | Clear |
| Brightness : | 180 cd/m² (Typ.) |
| Contrast Ratio : | 400:1 (Typ.) |
| Display Colors : | 262K (6-bit) |
| Response Time : | 23 (Typ.)(Tr+Td) |
| Viewing Angle : | 40/40/50/20 (Typ.)(CR≥10) (L/R/U/D) |
| Lamp Type : | WLED |
| Signal Interface : | CMOS (1 ch, 6-bit) |
| Input Voltage : | 3.0/5.0/15.0/-15.0V (Typ.)(VCC/VDD/VGON/VGOFF) |
Features and Advantages :
1. New and Industrial A grade perfect panels with stable supply
2. industrial control board supports the displays working 24 hours
3. Professional and industrial hardware and parts to guarantee its working normally in rough environment, Aluminum Front Bezel with rugged housing
4. Industrial design to protect the LCD screen, mounting on the outdoor application
5. VGA DVI interfaces
NEC NL2432HC17-01B Backlight System :
Lamp Type : WLED
Lamp Current : 18mA (Typ.)
Lamps Power Consumption : 200mW (Typ.)
About shiping:
We will test them strictly before shipping.
We will ship it in 1-3 working days after your paying.
We only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be
different for different countries.
Delivery time is approx:
United States / United Kingdom / Australia 7-14 working days.
Canada 7-25 working days.
France / Spain / Germany may take 7-20 working days.
Eastern Europe may take up to 16-30 working days.
Italy / Brazil / South America may take up to 30-50 working days.
Shipped by DHL Express (Need 3-6 working days to arrive)
NEC NL2432HC17-01B Signal Interface:
<
| Signal Category : | TTL |
| Signal Class : | CMOS (1 ch, 6-bit) |
| Input Voltage for Panel : | 3.0/5.0/15.0/-15.0V (Typ.)(VCC/VDD/VGON/VGOFF) |
| Panel Power Consumption : | 20mW (Typ.) |
Pictures about NEC NL2432HC17-01B :
