Antiglare Numeric Lcd Display AT050TN33 V.1 , 5 Inch Tft Lcd Panel Without Touch Panel
5.0" TN Antiglare AT050TN33 V.1 of numeric lcd display Innolux LCD Panel
INNOLUX AT050TN33 V.1 Mechanical & Electronics Features :
| Panel Brand : | INNOLUX |
| Panel Model : | AT050TN33 V.1 |
| Panel Type : | a-Si TFT-LCD , Panel |
| Panel Size : | 5.0 inch |
| Dot Resolution : | 480(RGB)×272 (WQVGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 109 PPI |
| Aspect Ratio : | 16:9 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.077×0.231 mm (H×V) |
| Pixel Pitch : | 0.231×0.231 mm (H×V) |
| Weight : | 65g (Typ.) |
| Surface : | Antiglare |
| Active Area : | 110.88×62.832 mm (H×V) |
| Bezel Area : | 113.90×65.85 mm (H×V) |
| Outline Dimension : | 120.7×75.8 mm (H×V) |
| Outline Depth : | 3.1±0.2 mm |
| Landscape or Portrait : | Landscape type |
| Touch Panel : | Without |
About Shipping:
we will test them strictly before shipping.
we will ship it in 1-3 working days after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be different for different countries.
Return and feedback:
All returns must be informed before returning.
The Buyer is ought to notify the seller of all returned items within 7 days after receiving the package. We reserve the right refusing any requirement that informs the seller longer than 7 days.
Exchange due to buyer wrong part ordered, buyer needs to pay 2-ways shipping fee.
Return items must have all original packaging and in good condition.
Return postage and insurance charge is non-refundable for refund or new shipment.
Shipping fees are non-refundable.
If you are pleased with your purchase, please leave us positive feedback once receiving the item, and we will return the feedback upon you.
If you have any problem with the outcome of the transaction or product, please don't respond with negative feedback before contacting us. we will do our best to resolve your case ASAP.
if you meet any questions,pls contact me first,i will try to solve for you. Negative feedback is not acceptable before contacting me.
INNOLUX AT050TN33 V.1 Backlight System :
<
| Lamp Position : | Edge light type |
| Lamp Type : | WLED |
| Lamp Amount : | 6S2P |
| Lamp Shape : | Array |
| Lamp Life Time : | 20K(Min.) (Hours) |
| Lamp Voltage : | 19.8±1.2V |
| Lamp Current : | 40±4mA |
| Lamps Power Consumption : | 792mW (Typ.) |
| Interface Type : | Included in panel signal interface |
| Lamp Driver Board : | No |
Picture for INNOLUX AT050TN33 V.1:
