14.0 inch Flat Rectangle Display LP140WH6-TJA1 LG LCD Panel with 1366*768

14.0 inch Flat Rectangle Display LP140WH6-TJA1 LG LCD Panel with 1366*768


Mechanical Features

Panel Size : 14.0 inch

Dot Resolution : 1366(RGB)×768 (WXGA)
Pixel Configuration : RGB Vertical Stripe
Pixel Density : 112 PPI
Aspect Ratio : 16:9 (H:V)
Form Factor : Flat Rectangle Display
Dot Pitch : 0.0755×0.2265 mm (H×V)
Pixel Pitch : 0.2265×0.2265 mm (H×V)
Weight : 190g (Max.)
Surface : Glare (Haze 0%), Hard coating (3H)
Active Area : 309.399×173.952 mm (H×V)
Outline Dimension : 322.3×198.68 mm (H×V)
Outline Depth : 1.27 (Typ.) mm
Landscape or Portrait : Landscape type
Touch Panel : Without

Feature:
1) 100% Brand New and never used Touch Screen Digitizer.
2) Tested before shipping and 100% working well.
3) Delivery in 3 working days after payment confirmed.
4) Excellent after-sale service.
5) Great replacements for your LCD panels’ sourcing replenishment.
6) Each screen will be tested before shipping and 100% working guarantee.

Optical Features

LG Display LP140WH6-TJA1 General Features

Panel Brand : LG Display
Panel Model : LP140WH6-TJA1
Panel Type : a-Si TFT-LCD , CELL
Panel Size : 14.0 inch
Resolution : 1366(RGB)×768 , WXGA
Display Mode : TN, Normally White, Transmissive
Active Area : 309.399×173.952 mm
Outline : 322.3×198.68 mm
Surface : Glare (Haze 0%), Hard coating (3H)
Glass Depth : 0.50+0.50 mm
Transmissivity : 6.1% (Typ.)(with Polarizer)
Contrast Ratio : 500:1 (Typ.)
Display Colors : 262K (6-bit) , CIE1931 45%
Response Time : 16 (Typ.)(Tr+Td)
Viewing Angle : 45/45/15/35 (Min.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Signal Interface : LVDS (1 ch, 6-bit) , 40 pins
Input Voltage : 3.3V (Typ.)

Questions & Answers:

Q1: How can you trust us?
- We are a professional team for the LCD panel international trade already for 6 years. We own the more professional & more competitive sourcing line & agency for the LCD Screen panels.
Q2: When can I get the update price?
- Within 24 hours after we get your inquiry.
Q3: What is your product capacity per day?
- 500-1000 pcs/day. We test each pcs LCD panels before shipment.
Q4: What is the payment term?
- T/T, Western Union, MoneyGram, PayPal.
Q6: Do you offer after-sale service?
- Yes, we do. We have strict QC system to make sure within our guarantee period(12 months), please contact us ASAP if there is any question, we will try our best to resolve it.
Q7: Which brands' LCD panel replacements could we handle?
- Our LCD screen panels contained but not limited to AUO, Chimei, Hitachi, Innolux, KOE, Tianma, LG, NEC, Samsung, Sharp, Optrex and more brand for the industrial TFT LCD module.

Q8: Do you provide samples?
- Yes, we are glad to offer you our samples for checking quality. If you are interested in some of our products, please feel free to contact us for
