5.9" 1080P LS059T1SX01 1080*1920 TFT LCD screen display with HDMI MIPI driver board with MIPI connector for VR product
Price:
USD
MOQ:
10
Delivery Time:
1-2days
Brand:
SHARP LCD Displays
Product Description
5.9" 1080P LS059T1SX01 1080*1920 TFT LCD screen display with HDMI MIPI driver board with MIPI connector for VR product
SHARP LS059T1SX01 General Features
Panel Brand : SHARP
Panel Model : LS059T1SX01
Panel Type : CG-Silicon , LCM
Panel Size : 5.9 inch
Resolution : 1080(RGB)×1920 , FHD
Display Mode : Normally Black, Transmissive
Active Area : 72.9×129.6 mm
Outline : 76.2×139.1 mm
Surface : Clear
Brightness : 400 cd/m² (Typ.)
Contrast Ratio : 1000:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 70%
Response Time : TBD
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 7S2P WLED
Signal Interface : MIPI , 30 pins
Panel Model : LS059T1SX01
Panel Type : CG-Silicon , LCM
Panel Size : 5.9 inch
Resolution : 1080(RGB)×1920 , FHD
Display Mode : Normally Black, Transmissive
Active Area : 72.9×129.6 mm
Outline : 76.2×139.1 mm
Surface : Clear
Brightness : 400 cd/m² (Typ.)
Contrast Ratio : 1000:1 (Typ.)
Display Colors : 16.7M (8-bit) , CIE1931 70%
Response Time : TBD
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 7S2P WLED
Signal Interface : MIPI , 30 pins
SHARP LS059T1SX01 Packing Form
| Amount per Box : | 120 pcs |
|---|---|
| Box Size : | 580×365×187 mm (L×W×H) |
| Box Gross Weight : | 8.5 Kgs |
Company Advantage:
Kyocera offers touch panels for all of our TFT-LCD products, from 3.5" to 12.1". Our touch panel's provide high quality, reliability and durability. Factory installed with a full factory warranty.
Custom touch solutions are also available from our Value Added assembly plant contains but not only for LCD Screen of Innolux ,AUO, Samsung, LG & Sharp.
• Resistive touch panels
• Film touch or glass touch panel options
• Custom touch solutions
