LMS700KF25-0 7.0 inch Samsung LCD Panel TN LCM 800×480 350nits WLED TTL 40pins
Samsung LMS700KF25-0 7.0 inch TN LCM 800×480 350nits WLED TTL 40pins
LMS700KF25-0 Main Parameters
| Panel Brand : | SAMSUNG SMD |
| Panel Model : | LMS700KF25-0 |
| Panel Type : | a-Si TFT-LCD , LCM |
| Panel Size : | 7.0 inch |
| Resolution : | 800(RGB)×480 , WVGA |
| Display Mode : | TN, Normally White, TMR |
| Active Area : | 152.4×91.44 mm |
| Outline : | 163.2×104×3.6 mm |
| Brightness : | 350 cd/m2 (Typ.) |
| Contrast Ratio : | 700 : 1 (Typ.) |
| Display Colors : | 16.2M (6-bit + FRC) |
| Response Time : | 16 (Typ.)(Tr+Td) |
| Viewing Angle : | 70/70/70/70 (Typ.)(CR≥10) (L/R/U/D) |
| Frequency : | 60Hz |
| Lamp Type : | 8S3P WLED |
| Signal Interface : | CMOS (1 ch, 8-bit) , 40 pins |
SAMSUNG SMD LMS700KF25-0 Mechanical Features
| Dot Resolution : | 800(RGB)×480 (WVGA) |
| Pixel Configuration : | RGB Vertical Stripe |
| Pixel Density : | 133 PPI |
| Aspect Ratio : | 15:9 (H:V) |
| Form Factor : | Flat Rectangle Display |
| Dot Pitch : | 0.0635×0.1905 mm (H×V) |
| Pixel Pitch : | 0.1905×0.1905 mm (H×V) |
| Weight : | 115g (Typ.) |
| Active Area : | 152.4×91.44 mm (H×V) |
| Bezel Area : | 155.4×94.44 mm (H×V) |
| Outline Dimension : | 163.2×104 mm (H×V) |
| Outline Depth : | 3.4±0.2 mm |
| Holes & Brackets : | Without |
| Landscape or Portrait : | Landscape type |
FAQ
Q1: What's price?
A1: We provide reasonable price and recommend suitable batteries to our customers.
Q2: What's delivery time?
A2: The delivery time is normally 1-3 working days after payment.
Q3: What's the payment?
A3: We accept T/T, Western Union, MoneyGram, Paypal
Q4: Can we visit your factory?
A4: Warmly welcome. Once we have your schedule, we will arrange
professional sales team to follow up your case.
Packaging & Delivery
Packaging Details:
Antistatic bag + Bubble bag + Foam box + Carton box
Delivery Detail:
1-3 working days after payment confirmed
Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk
| Panel Model | Brand | Size | Resolution |
| AMS549HQ02 | Samsung | 5.5" | 720×1280 |
| AMS520BQ12-0 | Samsung | 5.2" | 1080×1920 |
| AMS497DX12-0 | Samsung | 5.0" | 720×1280 |
| AMS163AN01 | Samsung | 1.63" | 320×320 |
| AMS510CV02 | Samsung | 5.1" | 1080×1920 |
| AMS510CV01 | Samsung | 5.1" | 1080×1920 |
| AMS302AK03 | Samsung | 3.0" | 720×480 |
| AMS353FD01-0 | Samsung | 3.5" | 480×800 |
| AMS499QP89-0 | Samsung | 5.0" | 1080×1920 |
| AMS529BY03 | Samsung | 5.3" | 1080×1920 |
| SDC 1.63 320×320 | Samsung | 1.63" | 320×320 |
| AMS499QP42-0 | Samsung | 5.0" | 1080×1920 |
LMS700KF25-0 Picture
