R213RFE-L01 INNOLUX a-Si TFT-LCD ,21.3 inch, 2048×1536 for 60Hz
R213RFE-L01 INNOLUX a-Si TFT-LCD ,21.3 inch, 2048×1536 for 60Hz
R213RFE-L01 Basic Information
| Panel Model | R213RFE-L01 |
|---|---|
| Panel Brand | INNOLUX |
| Descrition | a-Si TFT-LCD ,21.3 inch, 2048×1536 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C |
Packaging & Delivery
Packaging Details: Safe & Professional packing or as requirement for the LCD Screen replacements.
Delivery Detail: 2-3 days after receipt of payment
Payment terms: We accept T/T, PayPal, Western Union and others.
R213RFE-L01 Mechanical Features
| Dot Resolution | 2048(RGB)×1536 (QXGA) |
|---|---|
| Pixel Configuration | RGB Vertical Stripe |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Surface | Antiglare, Hard coating (3H) |
| Landscape or Portrait | Landscape type |
Warranty:
1. All panels’ grade is promised strictly same as original factory’s standard.
2. All brand-new Panels’ electronic functions are guarranted during warranty period of 1 year beginning with the invoice date.
3. We own 6-Year experience in the Medical LCD display, Aerospace LCD screen, Gaming LCD replacements, Military LCD screen, Kiosk LCD Display, Transportation LCD, industrial LCD panel and more.
4. ISO 9001 guarantee.
R213RFE-L01 Optical Features
| Display Mode | IPS, Normally Black, Transmissive |
|---|---|
| Brightness | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1400 : 1 (Typ.) (Transmissive) |
| Display Color | 16.7M/1.07B (8-bit / 8-bit + Hi-FRC) |
| White color Chromaticity | Wx:0.299; Wy:0.315 |
| Sunlight Readable | Y |
Why Choose US:
1. Prompt reply within 12 hours.
2. Understand inquiry in any language.
3. Products with top quality.
4. Very competitive prices.
5. 6-year experience in industrial LCD Screen replacements.
6. Distributor of famous brands Panel: Samsung, LG, Sharp, AUO, TPO, Tianma, Mitsubishi and more.
7. Fabulous after-sale service.
R213RFE-L01 Backlight System
| Lamp Type | WLED |
|---|---|
| Lamp Life Time | 50K(Min.) (Hours) |
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| N116BGE-P42 | Innolux | 11.6" | 1366×768 |
| M220ZGE-P01 | Innolux | 22.0" | 1680×1050 |
| V236BJ1-P01 | Innolux | 23.6" | 1366×768 |
| CT024TN01 V.X | Innolux | 2.4" | 240×320 |
| M215HGE-P02 | Innolux | 21.5" | 1920×1080 |
| F03003-05L | Innolux | 3.0" | 320×240 |
| EE027NA-02A | Innolux | 2.7" | 320×240 |
| M236HGE-P02 | Innolux | 23.6" | 1920×1080 |
We also have other industrial LCD panels, pls contact to us for the further information
