A-Si TFT-LCD LCM Auo Display Panel 13.3'' 1920×1080 G133HAN02.0 For Gaming / Medical Imaging
Price:
Negotiable
MOQ:
1
Delivery Time:
1-3 Working Days
Brand:
AUO
Product Description
1.General Description
G133HAN02.0 is a Color Active Matrix Liquid Crystal Display composed of a TFT LCD panel, a driver circuit, and LED backlight system.
The screen format is intended to support the 16:9 FHD, 1920(H) x1080(V) screen and 16.2M colors with LED backlight driving circuit.
All input signals are eDP (Embedded DisplayPort) interface compatible.
G133HAN02.0 is designed for industrial display applications.
2.AUO G133HAN02.0 Optical Details
| Luminance(cd/m²) | 400(Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry | Response(ms) | 27 (Typ.)(Tr+Td) |
| White Coordinate | Wx:0.313; Wy:0.329 | Display Colors | 16.2M (6-bit + FRC) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(5 points) |
| NTSC Ratio | 46% | sRGB | 64% coverage |
| Adobe RGB | 48% coverage | DCI-P3 | 47% coverage |
| Rec.2020 | 34% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
