Anti Glare 1920×1080 G133HAN01.0 13.3 Inch Auo LCD Display
Anti Glare 1920×1080 G133HAN01.0 13.3 Inch Auo LCD Display
Description Of AUO LCD Panel
G133HAN01.0 supports display 1920(RGB)×1080 (FHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 293.472(W)×165.078(H) mm, outline size of 309.7(W)×184.1(H)×10.1(D) mm, viewing area size of 295.07(W)×166.68(H) mm, with surface treament of Antiglare, net weight of 500g (Typ.).
AUO G133HAN01.0 Mechanical Details
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.05095×0.15285 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.15285×0.15285 (H×V) [166PPI] | |
| Mechanical Size : | Active Area(mm) | 293.472(H) × 165.078(V) | Bezel Area(mm) | 295.07(H) × 166.68(V) |
| Outline Dim.(mm) | 309.7(H) × 184.1(V) | Depth(mm) | 10.1 (Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | Wedge (PCBA Bent, T≥5.2mm) |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Mounting : | Side mounting holes (4-M2) on left, right bezel | |||
| Other Spec : | Weight | 500g (Typ.) | Treatment | Antiglare |
AUO G133HAN01.0 Optical Details
| Basic Information : | Luminance(cd/m²) | 400 (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)  |
Display Mode | AHVA, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 25 (Typ.)(Tr+Td) | |
| Color Performance : | White Coordinate | X:0.313; Y:0.329 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.25/1.33 (Typ./Max.)(5 points)  |
|
| 1931 Color Gamlt : | NTSC Ratio | 90% | sRGB | 100% coverage |
| Adobe RGB | 82% coverage | DCI-P3 | 90% coverage | |
| Rec.2020 | 67% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
