1000KG/H Industrial IQF Quick Tunnel Freezer Air Blast Freezer
Industrial Tunnel IQF Quick Freezer/Individual Quick Freezing Fast Freezer Air Blast Freezer
Product Description:
The shape of the tunnel freezer is a rectangular tunnel, in which cold air circulates and food is quickly frozen when passing through the tunnel.
The device has simple structure, fast freezing speed, can realize continuous production, and is suitable for assembly line processing.The food can be frozen within 60 minutes, and the center temperature can reach below -18°C. Incoming temperature/outgoing temperature: +15°C/-18°C. The equipment is designed and manufactured in accordance with HACCP requirements to ensure food hygiene and safety.
Product Categories
quick freezer.
The mesh belt tunnel quick freezer is suitable for quick-freezing processing of seafood, poultry meat, vegetables,
fruits, pasta, dairy products and other foods. The freezing amount can be 100Kg/h--2000Kg/h.
a. Simple structure, convenient operation and long service life.
b. The conveying mesh belt is made of high-strength SUS304 stainless steel mesh, which is safer to use, and the
frozen products will not leave traces directly on the surface of the mesh belt. Mesh belt width can be selected upon request.
c. According to the production requirements, the combination of single and double mesh belts can be selected.
d. The thermal insulation storage body is made of double-sided SUS304 stainless steel polyurethane storage board,
with inspection doors, double-layer sealing devices and heating devices to prevent freezing.
e. The air guide device in the warehouse adopts high-efficiency and low-noise axial flow fan and thermal fluctuation technology,and the freezing efficiencyis increased by about 15%-30%.
f. Use water to wash the cream to ensure cleanliness. The evaporator is made of aluminum alloy material, aluminum tube and aluminum fins, which is easy to clean. The design of variable blade distance can effectively prevent frost blocking and prolong the time of frost flushing. The unique liquid supply method makes the heat exchange more sufficient and the effect more obvious.
g. The imported frequency converter realizes inorganic speed regulation, and the freezing time can be adjusted continuously according to the needs, which can adapt to various freezing processes.
h. Stainless steel electric control box, stable quality, safe and reliable, easy to operate. The control system is equipped with a special alarmdevice and an emergency button to ensure the safe operation of the equipment.
Plate Belt Tunnel Quick Freezer
Plate belt tunnel quick freezer is suitable for quick-freezing processing of high-moisture, soft and liquid foods, such as fresh meat,fish fillets, shrimp, scallops, pasta and other foods. The freezing amount can be 100Kg/h--2000Kg/h.
Structural features:
a. Simple structure, convenient operation and long service life.
b. The storage body is made of rigid polyurethane foam, which has good thermal insulation performance. All internal parts are made of SUS304. high-quality stainless steel, which is easy to clean and meets HACCP requirements.
c. Imported stainless steel strips are used, with high toughness and smooth surface.
d. The ice scraping device of the feeding belt can reduce the damage to the steel belt caused by ice and foreign objects.
e. According to the production requirements, single and double strip combinations can be selected.
f. Use water to flush the cream to ensure cleanliness
g. The imported frequency converter realizes inorganic speed regulation, and the freezing time can be adjusted continuously according to the needs, which can adapt to various freezing processing
|
EQUIPMENT DESIGN BASIC PARAMETERS
|
||
|
1
|
device name
|
Frozen tunnel
|
|
2
|
structure type
|
straight line
|
|
3
|
frozen form
|
Down blow type
|
|
4
|
Air supply form
|
Down and out the back air flow
|
|
5
|
Dimensions (length*width*height mm)
|
15000*2200*2400
|
|
6
|
Main cold room length mm
|
15000mm
|
|
7
|
Mesh belt width
|
1200mm
|
|
8
|
Mesh belt form
|
316 Stainless Steel
|
|
9
|
Feed port length
|
1000mm
|
|
10
|
Outlet length
|
800mm
|
|
11
|
Door
|
800*1600*150*2 sets
|
|
12
|
Panel thickness
|
15CM
|
|
13
|
Panel material density
|
Double-sided stainless steel polyurethane board * 0.5 mm
|
|
14
|
Energy saving measures
|
Equipped with air blocking plate and inlet and outlet material wind shield device
|
|
15
|
Fan frequency modulation
|
The motor can be adjusted according to the demand of the goods
|
Product Application:
2. Meat: poultry meat, cut meat, etc.;
3. Noodles: dumplings, steamed stuffed buns, glutinous rice balls, spring rolls, etc.;
4. Conditioning food: marinated products, prepared dishes, etc.
