C9500-16X-2Q-A Cisco Switch Catalyst 9500 16-port 10G switch 2 x 40GE Network Module NW Adv. License
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Cisco
Product Description
C9500-16X-2Q-A Overview
C9500-16X-2Q-A is a Cisco Catalyst 9500 16-port 10G switch, 2 x 40GE Network Module, NW Adv. License. The Cisco Catalyst 9500 Series Switches are the next generation of enterprise-class core and aggregation layer switches, supporting full programmability and serviceability. Based on an x86 CPU, the Catalyst 9500 Series is Cisco's lead purpose-built fixed core and aggregation enterprise switching platform, built for security, IoT, and cloud. The Catalyst 9500 Series is the industry's first purpose-built 40 Gigabit Ethernet line of switches targeted for the enterprise campus.
Compare to Similar Item
| Product Code | C9500-16X-A | C9500-16X-2Q-A |
|---|---|---|
| Description | Catalyst 9500 16-port 10Gig switch, with Network Advantage | Cisco Catalyst 9500 16-port 10G switch, 2 x 40GE Network Module, NW Adv. License |
| DRAM | 16 G | 16 G |
| Flash | 16 G | 16 G |
| Dimensions (H x W x D) | 1.73 x 17.5 x 21.52 in | 1.73 x 17.5 x 21.2 in |
| Rack units (RU) | 1 RU | 1RU |
C9500-16X-2Q-A Specification
| Device Type | Switch - 16 ports - L3 - managed - stackable |
|---|---|
| Enclosure Type | Rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 16 x 10 Gigabit Ethernet + 2 x 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ |
| Performance | Switching capacity (full duplex): up to 480 Gbps ¦ Forwarding rate: up to 360 Mpps |
| Capacity | Indirect IPv4 routes: 64000 ¦ Host IPv4 routes: 80000 ¦ Indirect IPv6 routes: 32000 ¦ Host IPv6 routes: 40000 ¦ Multicast scale: 16000 ¦ QoS ACL scale: 18000 ¦ Security ACL scale: 18000 ¦ FNF entries: 512000 ¦ VLAN IDs: 4000 ¦ Switched virtual interfaces (SVIs): 4000 |
| MAC Address Table Size | 64K entries |
| Jumbo Frame Support | 9198 bytes |
| Routing Protocol | OSPF, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, PIM-SSM, policy-based routing (PBR), RIPng |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, SNMP, SNMP 3, TFTP, NETCONF, RESTCONF |
| Features | DHCP support, NAT support, PAT support, trunking, MPLS support, Non-Stop Forwarding (NSF), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Virtual Route Redundancy Protocol (VRRP) support, Access Control List (ACL) support, Quality of Service (QoS), Non-Stop Routing (NSR), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Remote Switch Port Analyzer (RSPAN), Hot Standby Router Protocol (HSRP) support, Virtual Routing and Forwarding (VRF), Maximum Likelihood Demodulation (MLD), Flexible NetFlow (FNF), Multicast Source Discovery Protocol (MSDP), MACsec support, integrated Wireshark, VLAN Double Tagging (Q-in-Q), Ethernet over MPLS (EoMPLS), Hierarchical Virtual Private LAN Service (H-VPLS), Private VLAN, Layer 3 VPN (L3VPN) support, CoAP support, Switched Port Analyzer (SPAN) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3ba |
| Power | AC 120/230 V (50 - 60 Hz) |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 1.7 in x 17.5 in x 21.5 in |
| Weight | 23.59 lbs |
