JL258A HPE JL258A - Aruba 2930F Switch Aruba 2930F 8G PoE+ 2SFP+ Switch
Aruba 2930F Switch Series is designed for customer creating digital workplaces optimized for mobile users with an integrated wired and wireless approach. These basic Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager and Aruba AirWave and are ideal for enterprise edge, SMB and branch offices. A powerful Aruba ProVision ASIC delivers performance and value supporting the latest SDN applications with future proof programmability. The 2930F supports 10GbE uplinks, PoE+, robust QoS, RIP routing, Access OSPF, ACLs, Tunneled Node and IPv6. This JL258A has 8x 10/100/1000 PoE+ ports and 2x 1000/10G SFP+ transceiver slots for high speed connectivity. PoE+ is supported with a power budget of 125 Watts.
| Product Code | JL258A | JL259A | JL260A | JL261A | JL262A |
|---|---|---|---|---|---|
| Type | Aruba 2930F 8G PoE+ 2SFP+ Switch | Aruba 2930F 24G 4SFP Switch | Aruba 2930F 48G 4SFP Switch | Aruba 2930F 24G PoE+ 4SFP Switch | Aruba 2930F 48G PoE+ 4SFP Switch |
| I/O ports and slots |
|
|
|
|
|
| Throughput | up to 41.7 Mp/s | up to 41.7 Mp/s | up to 77.4 Mp/s | up to 41.7 Mp/s | up to 77.4 Mp/s |
| Switching capacity | 56 Gb/s | 56 Gb/s | 104 Gb/s | 56 Gb/s | 104 Gb/s |
|
JL258A Specifications
|
|
|---|---|
| Product Model | Aruba JL258A |
| Number of Ports | 8 GE PoE+ and 2 SFP+ |
| Flash Memory Installed | 4 GB |
| Memory Technology | DDR3 SDRAM |
| RAM Installed | 1 GB |
| Form Factor | Rack-mountable |
| MAC Address Table Size | 32K entries |
| PoE Budget | 125 watt |
| Power Over Ethernet (PoE) | PoE+ |
| Product Type | Switch |
| Switching Type | Gigabit Ethernet |
| Port Type | 10/100/1000 (PoE+) |
| Ports Type (2nd) | 1 Gigabit / 10 Gigabit SFP+ (uplink) |
| Dimensions(W X H X D) | 10 X 1.7 X 10 inch |
| Operating Temperature | 0°C to 45°C |
| Operating Humidity | 15 - 95% (non-condensing) |
| Warranty | Limited Lifetime |
