S6720-LI Series Switch, Providing 16 10 Gig SFP+ and AC 110/220V 16 10 Gig SFP+, AC 110/220V S6720S-16X-LI-16S-AC
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Huawei
Product Description
S6720S-16X-LI-16S-AC Overview
HW S6720S-16X-LI-16S-AC is the HW S6720-LI series switch, providing 16 10 Gig SFP+ and AC 110/220V. The S6720-LI series switches (S6720-LI) are next-generation simplified 10GE fixed switches and can be used as 10GE access switches on campus networks and data center networks. The S6720-LI provides line-rate 10GE access ports and 40GE uplink ports. In addition, the S6720-LI delivers a wide variety of services, comprehensive security control policies, and various QoS features to help customers build scalable, reliable, manageable, and secure campus and data center networks.
Quick Spec
Table 1 shows the quick spec.
| Model | S6720S-16X-LI-16S-AC |
| Ports | 16 x 10 GE SFP+ ports |
| Power | Built-in AC power supply and Redundant Power Supply (RPS) |
| Packet forwarding rate | 240 Mpps |
| Switching capacity | 1.28 Tbit/s |
| Dimensions (W x D x H) | 420 x 220 x 43.6 mm |
The Modules
Table 2 shows the recommended products.
| Model | Description |
| eSFP-GE-SX-MM850 | Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.5km, LC) |
| SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
| S-SFP-GE-LH40-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 40km, LC) |
| eSFP-GE-ZX100-SM1550 | eSFP, GE, Single-mode Module (1550nm, 100km, LC) |
| SFP-GE-LX-SM1310-BIDI | BiDi Transceiver, eSFP, Tx1310nm/Rx1490nm, 1.25Gb/s, -9dBm, -3dBm, -19.5dBm, LC, SM, 10km |
| SFP-GE-LX-SM1490-BIDI | BiDi Transceiver, eSFP, Tx1490nm/Rx1310nm, 1.25Gb/s, -9dBm, -3dBm, -19.5dBm, LC, SM, 10km |
| SFP-GE-ZBXD1 | HW Optical Transceiver SFP-GE-ZBXD1, eSFP, GE, BIDI Single-mode Module (1570nm (Tx)/1490nm (Rx), 80km, LC) |
Compare to Similar Item
Table 3 shows the comparison.
| Model | S6720S-16X-LI-16S-AC | S6720S-26Q-LI-24S-AC |
| Ports | 16 x 10 GE SFP+ ports | 24 x 10 GE SFP+ ports, 2 x 40 GE QSFP+ ports |
| Power | Built-in AC power supply and Redundant Power Supply (RPS) | Built-in AC power supply and RPS |
| Packet forwarding rate | 240 Mpps | 240 Mpps |
| Switching capacity | 1.28 Tbit/s | 1.28 Tbit/s |
S6720S-16X-LI-16S-AC Specification
S6720S-16X-LI-16S-AC Specification |
|
| Ports | 16 x 10 GE SFP+ ports |
| Power | Built-in AC power supply and Redundant Power Supply (RPS) |
| Packet forwarding rate | 240 Mpps |
| Switching capacity | 1.28 Tbit/s |
| Dimensions (W x D x H) | 420 x 220 x 43.6 mm |
| Extended slots | Not supported |
| MAC address table | 32K MAC address learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses |
| VLAN features |
4K VLANs Guest VLAN and voice VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports VLAN mapping Basic QinQ and selective QinQ |
| IPv4 routing | Static routing, RIP, and OSPF VRRP Policy-based routing Routing policies |
| IPv6 routing | Static routing RIPng OSPFv3 |
| IPv6 features | Neighbor Discovery (ND) and ND snooping IPv6 Ping VRRP6 DHCPv6 snooping, DHCPv6 server, and DHCPv6 relay |
| Multicast | IGMPv1/v2/v3 snooping Fast leave IGMP snooping proxy Multicast Listener Discovery (MLD) snooping Port-based multicast traffic suppression Inter-VLAN multicast replication Controllable multicast |
| QoS/ACL | Traffic classification based on ACLs Traffic classification based on outer 802.1p fields, outer VLAN IDs, source MAC addresses, and Ethernet types Access control after traffic classification Traffic policing based on traffic classifiers Re-marking based on traffic classifiers Class-based packet queuing Associating traffic classifiers with traffic behaviors Rate limiting on inbound and outbound ports Traffic shaping based on ports and queues Tail drop Priority Queuing (PQ) Deficit Round Robin (DRR) PQ + DRR scheduling Weighted Round Robin (WRR) PQ + WRR scheduling |
| Reliability | STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s) BPDU protection, root protection, and loop protection RRPP ring topology and RRPP multi-instance Smart Link tree topology and Smart Link multi-instance, providing millisecond-level protection switchover Smart Ethernet Protection (SEP) G.8032 Ethernet Ring Protection Switching (ERPS) Enhanced trunk (E-trunk) |
| Security features | Defense against DoS, ARP, and ICMP attacks Binding of the IP address, MAC address, port number, and VLAN ID of a user Port isolation, port security, and sticky MAC MAC-Forced Forwarding (MACFF) Limit on the number of learned MAC addresses IEEE 802.1X authentication and the limit on the number of users on a port AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC CPU defense |
| Super Virtual Fabric (SVF) | SVF Client |
