CE6851-48S6Q-HI, Huawei CE6800 Switch, 48x10GE SFP+/6x40GE QSFP+/No Fan & PSU
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
2-3 days
Brand:
HUAWEI
Product Description
CE6851-48S6Q-HI Overview
Huawei CE6851-48S6Q-HI Switch (48-Port 10G SFP+, 6-Port 40GE QSFP+, 2*FAN Box,Without Fan and Power Module)
CloudEngine 6800 series switches are next-generation switches designed for data center and high-end campus networks, with high performance, high interface density, and low latency. They boast an advanced hardware design with high-density 10 GE/25 GE access interfaces, 40 GE/100 GE uplink interfaces, advanced data center features, high-performance stacking technologies, and flexible airflow capabilities.
Quick Spec
Table 1 shows the quick spec.
| Model | CE6851-48S6Q-HI |
| Power source type | AC |
| Heat dissipation mode | Air cooling |
| Airflow | Front-to-back or back-to-front, depending on the fan modules and power modules |
| Power module backup | 1+1 backup |
| Fan module backup | 1+1 backup not supported |
| Maximum power consumption | 245 W |
| Typical power consumption | 145 W (100% throughput, SFP+ cables on 48 ports and QSFP+ cables on 6 ports, double power modules) |
| Maximum heat dissipation | 836 BTU/hr |
| Typical heat dissipation | 495 BTU/hr (100% throughput, SFP+ cables on 48 ports and QSFP+ cables on 6 ports, double power modules) |
| Processor | 1.2 GHz, quad-core |
| DRAM Memory | 2 GB |
| NOR Flash | 16 MB |
| NAND Flash | 1 GB |
| Service port supporting the stack function | 10GE optical ports and 40GE optical ports |
CE6851-48S6Q-HI, Huawei CE6800 Switch, 48x10GE SFP+/6x40GE QSFP+/No Fan & PSU Specification
| CE6851-48S6Q-HI Specification | |
| Model | CE6851-48S6Q-HI |
| Power source type | AC |
| Heat dissipation mode | Air cooling |
| Airflow | Front-to-back or back-to-front, depending on the fan modules and power modules |
| Power module backup | 1+1 backup |
| Fan module backup | 1+1 backup not supported |
| Maximum power consumption | 245 W |
| Typical power consumption | 145 W (100% throughput, SFP+ cables on 48 ports and QSFP+ cables on 6 ports, double power modules) |
| Maximum heat dissipation | 836 BTU/hr |
| Typical heat dissipation | 495 BTU/hr (100% throughput, SFP+ cables on 48 ports and QSFP+ cables on 6 ports, double power modules) |
| Processor | 1.2 GHz, quad-core |
| DRAM Memory | 2 GB |
| NOR Flash | 16 MB |
| NAND Flash | 1 GB |
| Service port supporting the stack function | 10GE optical ports and 40GE optical ports |
