CE6865E-48S8CQ-B, Huawei CE6865E Series Switch, 48x25G SFP28/8x100G QSFP28/2xAC PSU
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
2-3 days
Brand:
HUAWEI
Product Description
CE6865E-48S8CQ-B Overview
Huawei CE6865E-48S8CQ-B switch offers exceptional performance with 48 * 25G SFP28 and 8 * 100G QSFP28 ports, ideal for high-demand data centers and enterprises seeking robust network solutions. Equipped with dual AC power supplies and enhanced cooling systems, it ensures reliable operations for critical infrastructure.
CE6865E-48S8CQ-B Product Highlights
- 48 * 25G SFP28 ports
- 8 * 100G QSFP28 ports
- Dual AC power supply
- Advanced cooling system
- High performance
Product Features Comparison
| Features | CE6865E-48S8CQ-B | CE6865E-24S2Q-H | CE8850-64CQ-EI | CE6870-48S6CQ-EI | CE12808S | CE5860-32C-EI |
|---|---|---|---|---|---|---|
| Ports | 48 * 25G, 8 * 100G | 24 * 25G, 2 * 100G | 64 * 100G | 48 * 25G, 6 * 100G | Variable modular | 32 * 100G |
| Power Supplies | 2 * AC | 2 * AC | 4 * AC/DC | 2 * AC/DC | Multiple options | 2 * AC |
| Cooling System | 4 * fan box | 4 * fan box | 8 * fan box | 4 * fan box | Modular fans | 5 * fan box |
| Data Center | Yes | Yes | Yes | Yes | Yes | Yes |
| Enterprise | Yes | No | Yes | No | Yes | Yes |
CE6865E-48S8CQ-B Product Application Scenarios
- High-density data centers
- Enterprise networking
- Core network aggregation
Optional Add-ons
| Model | Description |
|---|---|
| AC-Power-Supply-E | Additional AC power supply unit |
| Fan-Box-E | Replacement fan box |
| SFP28-Transceiver | 25G SFP28 optical transceivers |
CE6865E-48S8CQ-B, Huawei CE6865E Series Switch, 48x25G SFP28/8x100G QSFP28/2xAC PSU Specification
| CE6865E-48S8CQ-B Specification | |
| Model | CE6865E-48S8CQ-B |
| Processor | 1.4 GHz, four-core |
| DRAM Memory | 4 GB |
| NOR Flash | 64 MB |
| NAND Flash | 4 GB |
| Mean time between failures (MTBF) | 45.48 years |
| Mean time to repair (MTTR) | 1.52 hours |
| Fixed ports | Forty-eight 10GE SFP+ Ethernet optical ports Six 40GE/100GE QSFP28 Ethernet optical ports |
| Physical specifications | Dimensions (H x W x D): 43.6 mm x 442.0 mm x 420.0 mm |
| Relative humidity | 5% RH to 95% RH, noncondensing |
| Altitude | < 5000 m (16404 ft.) |
| Noise (sound pressure, 27°C) | Back-to-front airflow: < 55 dBA; Front-to-back airflow: < 55 dBA |
| Power source type | AC/DC/HVDC |
| Maximum power consumption | 282 W |
| Maximum heat dissipation | 962 BTU/Hr |
| Heat dissipation mode | Air cooling |
| Airflow | Front-to-back or back-to-front, depending on the fan modules and power modules |
| Power module backup | 1+1 backup |
| Fan module backup | 3+1 backup |
| Hot swap | Supported by all power modules and fan modules |
| Availability | 0.99999618 |
| Service port supporting the stack function | 10GE optical ports, and 100GE optical ports |
