CE6885-48YS8CQ-B, Huawei CE6800 Switch, 48x10GE electric/8x100GE QSFP28/2xAC PS
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
2-3 days
Brand:
HUAWEI
Product Description
CE6885-48YS8CQ-B Overview
The Huawei CE6885-48YS8CQ-B is a high-performance network switch designed for modern data centers and enterprise environments. With 48 x 10GE Ethernet ports, 8 x 100GE QSFP28 ports, dual AC power supplies, and efficient port side blowing, it offers unparalleled reliability and flexibility for complex networking needs.
CE6885-48YS8CQ-B Product Highlights
- 48 x 10GE electric ports
- 8 x 100GE QSFP28 ports
- Dual AC power supplies
- Port side air blowing
- High-capacity switching
Product Features Comparison
| Feature | CE6885-48YS8CQ-B | CE6851-48S6Q-H | CE6863-48S6CQ | CE6856-48S2Q-H | CE6855-48S6CQ | CE6860-48S6CQ | CE6655-48S8CQ |
|---|---|---|---|---|---|---|---|
| 10GE Ports | 48 | 48 | 48 | 48 | 48 | 48 | 48 |
| 100GE Ports | 8 | 6 | 6 | 2 | 6 | 6 | 8 |
| Power Supply | 2 x AC | 2 x AC | 2 x AC | 2 x AC | 2 x AC | 2 x AC | 2 x AC |
| Fan Box | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Air Flow Direction | Port side | Port side | Port side | Port side | Port side | Port side | Port side |
CE6885-48YS8CQ-B Product Application Scenarios
- Data center aggregation and core
- Enterprise network backbone
- High-performance computing environments
Optional Add-ons
| Model | Description |
|---|---|
| HW-AC-PSU | Additional AC Power Supply Unit |
| HW-QSFP28-CAB | QSFP28 Direct Attach Copper Cable |
| HW-FAN-BOX | Additional Fan Box for Cooling |
Huawei CE6885-48YS8CQ-B Specification
|
CE6885-48YS8CQ-B Specifications
|
|
| Model | CE6885-48YS8CQ-B |
| Port Configuration |
|
| Power Supply | 2 x AC power supply units |
| Cooling | 4 x fan boxes with port side blowing |
| Switching Capacity | 3.6 Tbps |
| Forwarding Performance | 1440 Mpps |
| Layer 2 Features |
|
| Layer 3 Features |
|
| QoS |
|
| ACL | Support for IPv4/IPv6 ACL |
| Management |
|
| Dimensions (WxDxH) | 440 mm x 460 mm x 43.6 mm |
| Max Power Consumption | 500W |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Relative Humidity | 5% to 95% non-condensing |
| MTBF | 200,000 hours |
| Certifications |
|
| Warranty | 1-year hardware warranty with 10 years of parts availability |
| MAC Address Table Size | 128K |
| Jumbo Frame Support | Up to 9216 bytes |
| Buffer Memory | 32 MB |
