BiDi Transceiver SFP+TX 1270nm/RX 1330nm 9.95~10.3Gb/s 0dBm 5dBm -18dBm LC 40km OSX040B03
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
CS
Product Description
OSX040B03 Overview
The HW OSX040B03 is a high-performance BiDi Transceiver designed for long-distance data transmission. This hot-pluggable SFP+ transceiver supports data rates from 9.95 to 10.3Gb/s, providing efficient and stable communication over distances up to 40km. Featuring LC connectors and operating at wavelengths TX 1270nm/RX 1330nm, this transceiver is ideal for various networking applications.
Quick Spec
| Data Transfer Rate | 9.95~10.3Gb/s |
| Transmission Distance | 40km |
| Wavelength | TX 1270nm/RX 1330nm |
| Connector Type | LC |
| Optical Output Power | 0dBm to 5dBm |
Product Features
- Supports data rates from 9.95 to 10.3Gb/s
- BiDi SFP+ for bidirectional communication over a single fiber
- Maximum transmission distance of 40km
- Uses LC connectors for reliable connections
- Operating wavelengths of TX 1270nm and RX 1330nm
Product Applications
- Long-haul telecom networks requiring high-speed data transfer
- Enterprise data centers needing efficient and stable communication
- Metropolitan Area Networks (MAN) for extended area coverage
Supported Options
| Accessory | Model |
| LC to LC Fiber Patch Cable | HW-LCLC-PC45 |
| BiDi SFP+ Transceiver | HW-OSX040B04 |
| Patch Panel for SFP+ Modules | HW-PP-SFP+ |
Compare to Similar Items
| Model | Differences |
| HW OSX020B03 | 20km transmission distance, different wavelength TX 1330nm/RX 1270nm |
| HW OSX040B04 | Supports data rates up to 11.3Gb/s |
| HW OSX040A03 | Supports dual-fiber transmission |
OSX040B03 Specification
OSX040B03 Specifications |
|
| Brand | HW |
| Product Name | OSX040B03 |
| Type | BiDi Transceiver |
| Form Factor | SFP+ |
| Transmit Wavelength | TX 1270nm |
| Receive Wavelength | RX 1330nm |
| Data Rate | 9.95~10.3 Gb/s |
| Transmit Power | 0 dBm |
| Receive Sensitivity | -18 dBm |
| Maximum Receiver Overload | 5 dBm |
| Connector Type | LC |
| Max Distance | 40 km |
| Operating Temperature | 0°C to 70°C |
| Compatibility | IEEE 802.3ae |
| Digital Diagnostics Monitoring (DDM) | Yes |
| Power Supply Voltage | 3.3V |
| Power Consumption | 1.5 W |
| EMI Standard | FCC Part 15 Class B |
| Laser Safety | IEC 60825-1 |
| RoHS Compliance | Yes |
| MTBF | 1,000,000 hours |
