J4858D, Aruba J4858D Transceiver, 1G SFP LC/500m MMF/Aruba Series
Aruba J4858D Overview
J4858D is an Aruba 1G SFP LC SX 500m OM2 MMF Transceiver.
Supported Devices
Figure 2 shows the front panel of J4858D.
Compare to Similar Items
Table 1 shows the comparison.
|
Product name (SKU) |
DOM - Digital Optical Monitoring (4x4 part ) |
Central wl (nm) |
Fiber mode |
Fiber diameter (µm) |
Modal bandwidth (MHz*km) |
Transmission distance |
|
HPE X121 1G SFP LC SX Transceiver (J4858C) Aruba 1G SFP LC SX 500m MMF XCVR (J4858D) |
Yes (1990-4395 & 1990-4415) |
850 |
MMF |
50/125 |
500 (OM2) 400 |
550 m (1804.46 ft) 500 m (1640.42 ft) |
|
62.5/125 |
200 (OM1) 160 |
275 m (902.23 ft) 220 m (721.78 ft) |
||||
|
HPE X121 1G SFP LC LX Transceiver (J4859C) Aruba 1G SFP LC LX 10km SMF XCVR (J4859D) |
Yes (1990-4116, 1990-4414, & 1990-4608) |
1310 |
SMF |
9/125 |
N/A |
10 km (6.21 miles) |
|
MMF |
50/125 |
500 (OM2) or 400 |
550 m (1804.46 ft) |
|||
|
MMF |
62.5/125 |
500 (OM2) |
550 m (1804.46 ft) |
|||
|
HPE X121 1G SFP LC LH Transceiver (J4860C) Aruba 1G SFP LC LH 70km SMF XCVR (J4860D) |
Yes (1990-4363) |
1550 |
SMF |
9/125 |
N/A |
70 km (43.49 miles) |
Aruba J4858D Specification
