TS-QDO-854H-01C/400G QSFP-DD SR4 Transceiver 850nm 50/100m MMF Optical Module
This 400G QSFP-DD SR4 optical transceiver operates at 850nm wavelength with 400Gbps full-duplex data rate, adopting PAM4 encoding technology and compatible with QSFP-DD MSA and IEEE 802.3bs standards. It is designed for short-reach transmission over multimode fiber, supporting 50m transmission on OM3 fiber and 100m on OM4 fiber, with MTP/MPO-12 connector for easy fiber connection. Equipped with DDM/DOM function, it enables real-time monitoring of operating status including temperature, voltage and optical power. The transceiver features compact QSFP-DD form factor, low power consumption and high reliability, making it an ideal solution for 400G short-reach interconnections in data centers, cloud computing and high-speed enterprise networks.
Figure 1 shows the front panel of 400G QSFP-DD SR4 .
Table 1 shows the Quick Specs.
| Parameter | Specification |
|---|---|
| Form Factor | QSFP-DD |
| Data Rate | 400Gbps |
| Wavelength | 850nm |
| Transmission Distance | 50m/100m |
| Fiber Type | MMF (OM3/OM4) |
| Parameter | Details |
|---|---|
| Optical Form Factor | QSFP-DD (Quad Small Form-factor Pluggable - Double Density) |
| Nominal Bit Rate | 400Gbps (8×50G PAM4) |
| Operating Wavelength | 850nm (VCSEL Array) |
| Transmission Reach | 50m over OM3 multimode fiber, 100m over OM4 multimode fiber |
| Fiber Connector | MTP/MPO-12 (MPO female, key-up) |
| Operating Temperature | 0°C ~ 70°C (Commercial Grade, 0-70C) |
| Power Supply Voltage | 3.3V ±5% |
| Digital Diagnostics | Support DDM/DOM (Digital Diagnostic Monitoring) |
| Compliance | QSFP-DD MSA, IEEE 802.3bs 400GBASE-SR4 |
| Encoding | PAM4 |
| Laser Type | VCSEL |
