TS-OP-314H-02C/400G OSFP FR4 Transceiver with 400Gbps Data Rate 2km Transmission Distance and CWDM4
Price:
Negotiable
MOQ:
1
Delivery Time:
2-3 days
Brand:
HUAWEI
Product Description
400G OSFP FR4 Overview
The 400G OSFP FR4 transceiver is a high-performance, hot-pluggable optical module engineered for 400 Gigabit Ethernet and data center interconnect (DCI) applications, supporting reliable 2km transmission over single mode fiber (SMF). Adopting advanced PAM4 modulation technology and CWDM4 wavelength scheme (1271/1291/1311/1331nm), it features a 4×100G channel configuration with an aggregate data rate of 400Gbps and 53.125GBd per-lane signaling rate, delivering high bandwidth and spectral efficiency for mid-range network interconnections.
Figure 1 shows the front panel of 400G OSFP FR4.
Quick Specs.
Table 1 shows the Quick Specs.
| Parameter | Specification |
|---|---|
| Data Rate | 400Gbps (4×100G PAM4) |
| Transmission Distance | 2km over Single Mode Fiber (SMF) |
| Wavelength | CWDM4 1271/1291/1311/1331nm |
| Form Factor | Hot-pluggable OSFP |
| Operating Temp | 0~70℃ |
| Power Consumption | ≤10W |
Detailed Specification
| Category | Parameter | Min | Typ | Max | Unit |
|---|---|---|---|---|---|
| Electrical | Data Rate per Lane | - | 106.25 | - | Gbps |
| Signaling Rate | - | 53.125 | - | GBd | |
| Power Supply Voltage | 3.135 | 3.3 | 3.465 | V | |
| Electrical Interface | - | 400GAUI-8 | - | - | |
| Optical | Transmitter Wavelength | 1271 | - | 1331 | nm |
| TX Launch Power | -3.3 | - | +3.5 | dBm | |
| RX Sensitivity | - | - | -7.3 | dBm | |
| Fiber Type | - | Single Mode Fiber (SMF) | - | - | |
| Connector Type | - | Duplex LC | - | - | |
| Mechanical & Env | Form Factor | - | OSFP MSA Compliant | - | - |
| Operating Temperature | 0 | - | 70 | ℃ | |
| Storage Temperature | -40 | - | 85 | ℃ | |
| Power Dissipation | - | - | 10 | W | |
| Humidity (Storage) | 5 | - | 95 | % | |
| Compliance | Protocol Compliance | - | IEEE802.3bs,OSFP MSA | - | - |
| Environmental | - | RoHS | - | - |
