800G OSFP VR8 MPO Optical Transceiver with 800Gbps Data Rate, 850nm VCSEL Technology, and 50m OM4 MMF Reach
Product Overview
The 800G OSFP VR8 MPO Optical Transceiver is a cutting-edge solution designed for ultra-high bandwidth requirements in next-generation AI data centers and High-Performance Computing (HPC) networks. Utilizing advanced 850nm VCSEL technology,this module delivers a stable 800Gbps data rate over short distances, ensuring low latency
and high energy efficiency for mission-critical interconnections.
Figure 1 shows the front panel of 800G OSFP VR8 MPO.
- Data Rate: 800Gbps (8x112G PAM4)
- Wavelength: 850nm VCSEL
- Connector Type: MPO-12/APC or MPO-16
- Transmission Distance: Up to 30m (OM3) / 50m (OM4) MMF
- Form Factor: OSFP (Octal Small Form-factor Pluggable)
- Power Consumption: < 14W
- Compliance: IEEE 802.3ck, OSFP MSA, RoHS compliant
| Feature | 800G OSFP VR8 | 800G OSFP SR8 | 800G OSFP DR8 |
|---|---|---|---|
| Fiber Type | Multimode (MMF) | Multimode (MMF) | Singlemode (SMF) |
| Max Distance | 50m (OM4) | 100m (OM4) | 500m |
| Laser Source | 850nm VCSEL | 850nm VCSEL | 1310nm EML/SiPh |
| Primary Use | Intra-rack AI clusters | Inter-rack connection | Campus/Spine-Leaf |
We provide a 1-year warranty and lifetime technical support for all our 800G optical transceivers. Each unit is individually tested for signal integrity and compatibility before shipping, ensuring industrial-grade reliability for your data center infrastructure.
