800G OSFP Loopback Module MSA Compliant for Datacom Testing
Professional Product Introduction
The 800G OSFP Loopback Module is a critical diagnostic tool designed for high-density 800G network equipment testing. As data centers transition to 800Gbps architectures, this MSA-compliant loopback provides a reliable solution for signal integrity testing, port verification, and thermal profiling. Supporting 8x112G PAM4 modulation, it mimics real-world transceiver power and thermal loads without the need for expensive optical cables.
Figure 1 shows the front panel of 800G OSFP.
| Parameter | Specification Details |
|---|---|
| Data Rate | 800Gbps (Aggregate); Supports 8x112G PAM4 |
| Compliance | OSFP MSA, IEEE 802.3ck, RoHS 2.0 |
| Form Factor | OSFP Type 2 (Flat Top / Finned optional) |
| Power Consumption | Configurable up to 30W (4 Independent regions) |
| Operating Temp | Commercial (0°C to 70°C) / Industrial (0°C to 85°C) |
| Interface | 2-wire I2C for Digital Diagnostic Monitoring (DDM) |
Q: What is the primary difference between an 800G OSFP Loopback and standard transceivers?
Unlike active optical transceivers, a loopback module does not contain lasers or optical fiber. It is designed to loop the high-speed electrical signals back to the host port. This makes it a cost-effective solution for validating electrical performance, BER (Bit Error Rate) testing, and thermal management of OSFP ports in switches and routers.
Q: Is this 800G OSFP Loopback compatible with major hardware vendors?
Yes. Our modules are fully OSFP MSA compliant, ensuring seamless physical and electrical compatibility with mainstream hardware from vendors like Cisco, Arista, NVIDIA/Mellanox, and Juniper. They are designed to fit standard OSFP cages perfectly.
Q: How does the module handle thermal simulation?
The module features built-in heat dissipation structures and supports power simulation up to 30W. Users can configure specific power loads via the I2C interface to emulate different transceiver power classes, allowing engineers to test the cooling capacity of their network systems accurately.
Q: What is the warranty policy for LonRise 800G products?
We provide a 1-year replacement warranty and lifetime technical support for all our loopback products. Every unit undergoes rigorous automated testing and signal integrity verification before shipment.
Q: What are the shipping options for international orders?
We offer fast global shipping via DHL, FedEx, and UPS. Standard lead time for stock items is 2-3 business days. We maintain a consistent inventory of 800G testing components to support your urgent lab requirements.
