Yaskawa SGMJV-08ADE6S 750W 200V AC Servo Motor Sigma 5 Original
Price:
Negotiable
MOQ:
1
Delivery Time:
2-3 days
Brand:
Siemens
Product Description
Sinamics SGMJV-08ADE6S Overview
The SGMJV-08ADE6S is a high-performance 750W medium-inertia AC servo motor from Yaskawa’s Sigma 5 series. It delivers stable torque, fast response, and high precision with a 20-bit incremental encoder, supporting speeds up to 6000 rpm. Designed for reliable operation in industrial automation, CNC machines, assembly lines, and packaging equipment, this motor features a compact 80 mm frame, oil seal, and no brake for flexible installation. It offers high efficiency, low vibration, and long service life, making it an ideal drive solution for precision motion control systems.
Figure 1 shows the front panel of SGMJV-08ADE6S.
Quick Specs.
Table 1 shows the Quick Specs
| Item | Value |
|---|---|
| Model | SGMJV-08ADE6S |
| Power | 750W (0.75kW) |
| Voltage | 200V AC |
| Torque | 2.39 Nm rated |
| Speed | 3000 rpm rated, 6000 rpm max |
| Type | Medium inertia, brushless |
Detailed Specification
| Parameter | Details |
|---|---|
| Model Number | SGMJV-08ADE6S |
| Series | Yaskawa Sigma 5 (SGMJV) |
| Rated Output | 750 W / 0.75 kW |
| Rated Voltage | 200 V AC |
| Rated Current | 4.7 A |
| Rated Torque | 2.39 N·m |
| Peak Torque | 8.36 N·m |
| Rated Speed | 3000 rpm |
| Max Speed | 6000 rpm |
| Encoder | 20-bit incremental |
| Inertia | Medium inertia |
| Brake | No brake |
| Oil Seal | With oil seal |
| Frame | 80 mm flange |
| Protection | Industrial grade |
| Application | CNC, automation, packaging, assembly |
