FANUC A06B-6096-H206 Dual-axis Servo Amplifier Module with FSSB Interface and 5.3 kW Power for CNC Systems
Price:
Negotiable
MOQ:
1
Delivery Time:
2-3 days
Brand:
Siemens
Product Description
Sinamics A06B-6096-H206 Overview
The A06B-6096-H206 is a high-performance dual-axis servo amplifier module from FANUC, belonging to the Alpha i series, model SVM2‑40/40. It features the FSSB optical serial interface for stable, high-speed communication with FANUC CNC systems. Designed for precision control in industrial automation, it drives FANUC Alpha servo motors and is widely used in CNC machining centers, robots, and automated production lines. This module ensures reliable, accurate motion control, high efficiency, and long service life for demanding industrial environments.
Figure 1 shows the front panel of A06B-6096-H206.
Quick Specs.
Table 1 shows the Quick Specs
| Item | Detail |
|---|---|
| Part Number | A06B-6096-H206 |
| Brand | FANUC |
| Type | 2-Axis Servo Module |
| Model | SVM2-40/40 |
| Interface | FSSB |
Detailed Specification
| Parameter | Value |
|---|---|
| Manufacturer | FANUC |
| Series | Alpha i / Alpha Series |
| Type | Dual-axis servo amplifier module |
| Model | SVM2-40/40 |
| Input Voltage | 283–325V DC |
| Rated Output | 12.5 A per axis |
| Power | 5.3 kW |
| Interface | FSSB (Fanuc Servo Serial Bus) |
| Compatible Motors | Alpha 6/2000, 12/2000 |
| Compatible Controls | 0i, 16i, 18i, 21i |
| Dimensions | 380 × 60 × 307 mm |
| Weight | 8 kg |
| Application | CNC machine tools, robotics, automation |
