Siemens 6AV2124-0MC01-0AX0 SIMATIC HMI TP1200 Comfort Touch Panel Original New
Price:
Negotiable
MOQ:
1
Delivery Time:
2-3 days
Brand:
Siemens
Product Description
Sinamics 6AV2124-0MC01-0AX0 Overview
6AV2124-0MC01-0AX0 is the Siemens SIMATIC HMI TP1200 Comfort industrial touch panel, designed for reliable visualization and operation in automation systems. It features a 12.1-inch widescreen TFT display with 1280×800 resolution and 16 million colors, delivering clear visuals even in industrial environments.
Figure 1 shows the front panel of a06b-6102-h111.
Quick Specs.
Table 1 shows the Quick Specs
| Item | Specification |
|---|---|
| Model | 6AV2124-0MC01-0AX0 |
| Type | SIMATIC HMI TP1200 Comfort |
| Display | 12.1" TFT, 1280×800, 16M colors |
| Operation | Touch operation |
| Interfaces | PROFINET, MPI/PROFIBUS DP, USB |
| Power | 24 VDC |
| Protection | Front IP65, Rear IP20 |
Full Specification Table
| Parameter | Details |
|---|---|
| Part Number | 6AV2124-0MC01-0AX0 |
| Product Line | SIMATIC HMI Comfort Panel |
| Display Size | 12.1-inch widescreen |
| Display Type | TFT color display |
| Resolution | 1280 × 800 pixels |
| Color Depth | 16 million colors |
| User Memory | 12 MB |
| Operating System | Windows CE 6.0 |
| Configuration Software | WinCC Comfort V11 and above |
| Communication | PROFINET, MPI / PROFIBUS DP |
| USB Ports | 3 × USB (host + device) |
| Supply Voltage | 24 V DC |
| Power Consumption | Typical 20 W |
| Front Protection | IP65 |
| Rear Protection | IP20 |
| Operating Temperature | 0°C ~ +50°C |
| Dimensions (W×H×D) | 330 × 241 × 65 mm |
