Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
Price:
Negotiable
MOQ:
1
Delivery Time:
2-3 days
Brand:
Huawei
Product Description
Huawei S5755-H48T4Y2CZ Overview
The Huawei CloudEngine S5755‑H48T4Y2CZ is a high‑performance, high‑density gigabit access switch designed for modern campus networks and data center edge deployment. It delivers 48 fixed 10/100/1000Base‑T ports for end‑device connectivity, paired with four 25GE SFP28 and two 100GE QSFP28 uplink ports to support high‑bandwidth aggregation and interconnection
Figure 1 shows the front panel of S5736-S24S4XC.
Quick Specs
| Item | Details |
|---|---|
| Model | CloudEngine S5755‑H48T4Y2CZ |
| Fixed Ports | 48×10/100/1000Base‑T, 4×25GE SFP28, 2×100GE QSFP28 |
| Switching Capacity | 944 Gbps / 2.4 Tbps |
| Forwarding Performance | 450 Mpps |
| Chassis | 1U, 442×420×43.6 mm |
| Weight | 7.83 kg |
| Power | 1+1/N+1 backup, AC/DC support |
| Key Features | VXLAN, MACsec, IPv4/IPv6 dual stack, M‑LAG |
Huawei S5755-H48T4Y2CZ Specification
| Parameter | Specification |
|---|---|
| Basic Info | |
| Product Name | Huawei CloudEngine S5755‑H48T4Y2CZ Switch |
| Port Configuration | 48×10/100/1000Base‑T Ethernet ports
|
| Switching Capacity | 944 Gbps (full duplex) / 2.4 Tbps |
| Forwarding Rate | 450 Mpps |
| Physical | |
| Dimensions (W×D×H) | 442 mm × 420 mm × 43.6 mm (1U) |
| Weight | 7.83 kg |
| Power | |
| Power Supply | 180W AC, 600W AC, 1200W DC (pluggable)
|
| Input Voltage | AC: 100–130V / 200–240V, 50/60Hz
|
| Power Consumption | ~92W (full ports, dual power) |
| Environment | |
| Operating Temp | –5°C to 45°C |
| Storage Temp | –40°C to 70°C |
| Humidity | 5%–95% (non‑condensing) |
| Software Features | |
| Network Virtualization | VXLAN, BGP‑EVPN, UVF |
| Reliability | M‑LAG, stack, hot‑swap, graceful restart |
| Security | MACsec, 802.1X, ACL, port security |
| QoS | Traffic classification, policing, scheduling, congestion management |
| Management | CLI, Web, SNMP, NETCONF/YANG, CampusInsight |
| Protocols | IPv4/IPv6 dual stack, OSPF, BGP, VLAN, STP/RSTP/MSTP |
