Huawei PDC240S12-CN 240W DC 12V Output Hot-Swappable Power Supply Module for Network Switches
HUAWEI PDC240S12-CN Overview
The Huawei PDC240S12-CN is a high-efficiency, hot-swappable DC-DC power supply module designed for enterprise-level network switching equipment. It converts a wide range of standard telecom DC voltages (-48V, +48V, -60V) into a stable 12V DC output, delivering up to 240 watts of power. Engineered for seamless integration with Huawei S620 series switches, its hot-swap capability allows for installation or replacement without powering down the host system, ensuring maximum uptime and reliability. This module provides robust protection against electrical faults and operates efficiently across a wide temperature range, making it an ideal power solution for critical data center and telecommunications infrastructure.
Table 1 shows the Quick Specs.
| Parameter | Specification |
|---|---|
| Model | PDC240S12-CN |
| Manufacturer | Huawei |
| Type | DC Input Power Module |
| Input Voltage | -48V / +48V / -60V DC |
| Output | 12V DC, 240W |
| Feature | Hot-Swappable |
| Application | For Huawei S620 Series Switches |
HUAWEI PDC240S12-CN pecification
| Parameter | Details |
|---|---|
| Part Number | PDC240S12-CN (Code: 10907098) |
| Input Voltage Range | +48V DC: 38.4V ~ 57V DC
|
| Output Voltage | 12V DC |
| Output Power | 240 Watts |
| Output Current | 20 Amps (Max.) |
| Form Factor | Plug-in Module |
| Cooling | Passive / Forced Air (System Dependent) |
| Operating Temperature | -40°C to +65°C (Standard) |
| Isolation | Input to Output Isolation |
| Protection Features | Over Voltage, Over Current, Short Circuit, Over Temperature |
| Dimensions | Standard Switch Module Size |
| MTBF | > 100,000 hours |
| Certifications | Safety & EMC compliant (CE, FCC) |
| Warranty | 36 Months |
