The Huawei SFP-10G-BXU1 is a high-performance, cost-effective SFP+ Bi-Directional (BIDI) optical transceiver module designed for 10G Ethernet applications. By integrating a Wavelength Division Multiplexing (WDM) splitter, it transmits and receives signals over a single strand of single-mode fiber (SMF), cutting your cabling infrastructure costs in half.

Operating at TX 1270nm / RX 1330nm with a maximum transmission distance of up to 10 kilometers, this module offers full compatibility with Huawei enterprise switches, routers, and data center equipment. Equipped with Digital Diagnostic Monitoring (DDM/DOM), it allows real-time monitoring of critical parameters such as laser power, temperature, and voltage.

Key Features:

• Maximize Fiber Utilization: Single-strand fiber transmission (BIDI) saves up to 50% on fiber patch cords.
• Plug-and-Play Hot-Swappable: Minimizes network downtime during upgrades or maintenance.
• Industrial Reliability: Built with high-quality components, supporting an MTBF of over 1 million hours.
• Fully Standard-Compliant: Adheres strictly to SFP+ MSA, IEEE 802.3ae, and RoHS safety certifications.

Figure 1 shows the front panel of SFP-10G-BXU1.

The SFP-10G-BXU1 must always be paired with its counterpart module SFP-10G-BXD1 (or any other compatible TX1330nm/RX1270nm 10km BIDI module) at the opposite end of the link. Since the BXU1 transmits at 1270nm and receives at 1330nm, the remote device must transmit at 1330nm and receive at 1270nm to establish a successful optical handshake.

A: Yes. Our Huawei SFP-10G-BXU1 modules are coded and rigorously tested on various Huawei hardware environments (including CloudEngine, Quidway S-series switches, and NetEngine routers) to ensure seamless compatibility, optimal DDM performance, and error-free link aggregation without triggering any system alerts.

A: No, you cannot. A BIDI module uses Wavelength Division Multiplexing (WDM) to split wavelengths over a single fiber strand, whereas standard dual-fiber 10G LR modules use separate fibers for TX and RX at a unified 1310nm wavelength. They are optically incompatible and cannot build a link.

A: Cost savings on infrastructure. The SFP-10G-BXU1 uses Bi-Directional technology, requiring only one fiber core instead of two. If you have limited fiber leasing or lack physical fiber lines in your datacenter or campus backbone, this module instantly doubles your fiber capacity without laying new cables.

A: Absolutely. It is 100% hot-swappable. You can insert or remove the transceiver from any active SFP+ slot without rebooting the host switch or causing disruptions to other running network ports.

Every single SFP-10G-BXU1 unit undergoes strict quality tracking before dispatch. We perform comprehensive laser performance measurements, spectrum verification, and real-switch hardware compatibility checks via our internal automated testing lab to ensure zero packet drop and long-term running stability.

• 1-Year Warranty: We offer a full 1-year warranty for any functional issues not caused by physical damage or improper handling.
• 30-Day Money-Back Guarantee: If you encounter unexpected system-level incompatibility issues, you can request an exchange or refund within 30 days of arrival.

• Safe Packing: Anti-static ESD defensive grid packaging ensures your optical modules arrive safely without dust contamination on the optical sub-assembly (OSA).
• Fast Shipping: Items are typically dispatched via international premium couriers (DHL Express, FedEx, UPS) within 2-3 business days. Tracking numbers will be synced to your mailbox automatically.
