SFP-10G-BXD1, Huawei SFP-10G Series Optical Transceiver, 10G SFP+, BIDI TX1330/RX1270, 10km SM
The SFP-10G-BXD1 Huawei compatible SFP+ optical transceiver is a high-performance bidirectional (BIDI) module designed for 10G Ethernet links over single-mode fiber (SMF) up to 10km. Operating at 1330nm TX / 1270nm RX wavelengths, it enables full-duplex communication over a single LC fiber strand, significantly reducing fiber cabling costs in enterprise and telecom networks.
This hot-swappable SFP+ module supports 10GBASE-BX standard, ensuring seamless compatibility with Huawei switches, routers, and other networking devices that require high-speed optical connectivity. With Digital Diagnostic Monitoring (DDM/DOM), users can monitor real-time optical parameters such as temperature, voltage, and optical power for improved network stability.
Built for reliability and long-distance transmission, the SFP-10G-BXD1 is widely used in data centers, enterprise networks, FTTH backhaul, and telecom infrastructure. It works as a paired module with SFP-10G-BXU1, forming a complete bidirectional optical link.
Figure 1 shows the front panel of SFP-10G-BXD1.
- 10G SFP+ BIDI transceiver (single-fiber solution)
- 1330nm TX / 1270nm RX wavelength
- Transmission distance up to 10km (SMF)
- Transmission distance up to 10km (SMF)
- LC duplex connector
- Hot-pluggable SFP+ MSA compliant
- Supports DDM/DOM monitoring
- Low power consumption & high stability
- Fully compatible with Huawei networking equipment
| Item | Details |
|---|---|
| Form Factor | SFP+ |
| Data Rate | 10Gbps |
| Protocol | 10GBASE-BX |
| Wavelength | 1330nm / 1270nm |
| Fiber Type | Single-mode fiber (SMF) |
| Max Distance | 10km |
| Connector | LC Simplex |
| DDM | Supported |
| Operating Temperature | 0°C ~ 70°C (or industrial -40°C ~ 85°C optional) |
| Power Consumption | Low power design |
Unlike traditional dual-fiber modules, the SFP-10G-BXD1 uses BiDi (bidirectional) technology, which allows:
- One fiber for both transmitting and receiving
- Paired operation with SFP-10G-BXU1
- Reduced fiber deployment cost by up to 50%
- Ideal for dense or limited fiber infrastructure environments
This module is compatible with:
- Huawei switches & routers (SFP+ 10G ports)
- Enterprise Ethernet switches
- Data center aggregation switches
- Any MSA-compliant 10G SFP+ port (vendor-dependent)
- Data center interconnect (DCI)
- Enterprise network backbone
- Metro Ethernet access networks
- FTTH / FTTx infrastructure
- Telecom carrier transmission systems
- Uses only one fiber instead of two
- Lower deployment cost
- Easier cable management
- Same 10Gbps performance as LR modules (within 10km range)
- Better scalability in fiber-limited environments
It is used for 10G optical transmission over single-mode fiber up to 10km, mainly in enterprise and telecom networks.
Yes. It must be used with SFP-10G-BXU1 for proper bidirectional communication.
- SR uses multimode fiber (short range, ~300m)
- LR uses dual-fiber single-mode (~10km, 2 fibers)
- BXD1 uses single fiber (1 strand only) with BiDi technology
Yes, if the switch supports MSA-compliant SFP+ modules, but compatibility depends on vendor restrictions.
Yes, it will work without monitoring, but DDM provides real-time diagnostics for better maintenance.
Single-mode fiber (SMF), typically OS2 LC simplex cable.
The link will not establish because wavelengths must match correctly (TX/RX reversed pair design).
Our module is manufactured and tested under strict quality control, ensuring:
- 100% compatibility testing
- Stable optical performance
- Low bit error rate (BER)
- Industrial-grade reliability
- Plug-and-play deployment
