PDC1000S12-DB, Huawei, Power Module, 1000W DC/Front Airway/Panel Side Outlet

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: 2-3 days

Brand: HUAWEI

Product Description

HUAWEI PDC1000S12-DB Overview

Introducing the Huawei PDC1000S12-DB, a robust 1000W DC power module designed for efficient and reliable power delivery. This module features a front-to-panel airway design, ensuring optimal cooling and performance. Ideal for various applications, the PDC1000S12-DB offers high efficiency and durability. Discover the power of advanced technology with Huaweis PDC series.

Figure 1 shows the front panel of PDC1000S12-DB.

Quick Spacs

Power Rating	1000W
Airflow Direction	Front to panel
Output Voltage	12V DC
Cooling Method	Forced Air
Dimensions (HxWxD)	41x114x265 mm

Supported Options

Mounting Bracket	MB-PDC12-HW
Cooling Fan	CF-PDC-1000
Power Cable	PC-12V-HW

Compare to Similar Items

Model	Difference
Huawei PDC800S12-DB	800W power rating, smaller size
Huawei PDC1200S12-DB	1200W power rating, higher output voltage
Huawei PDC1000S24-DB	24V DC output voltage

HUAWEI PDC1000S12-DB Specification

PDC1000S12-DB Specifications
Brand	Huawei
Model Name	PDC1000S12-DB
Power Output	1000W
Input Voltage	220V AC
Output Voltage	12V DC
Efficiency	92%
Cooling Method	Front-to-rear airflow
Operating Temperature Range	-10°C to 55°C
Storage Temperature Range	-40°C to 70°C
Humidity Range	5% - 95% (non-condensing)
Altitude	0 to 3000m
Dimensions (HxWxD)	40mm x 80mm x 200mm
MTBF	500,000 hours
Protection Features	Overvoltage, Overcurrent, Overtemperature
Compliance	CE, RoHS
Cooling System	Fan-based cooling
Connector Type	Terminal block
Power Factor Correction	Active PFC
Warranty	3 Years
Application	Imaging systems, networking, telecommunications
Certifications	UL, TUV
