Huawei AC6508 Wireless Access Controller, 10GE, 512 AP Management, Enterprise WLAN

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: 2-3 days

Brand: Huawei

Product Description

Huawei AC6508 Overview

The Huawei AC6508 is a compact, high-performance Wireless Access Controller (WLAN AC) purpose-built for small and medium-sized enterprises (SMEs). It unifies wired and wireless network management by integrating a built-in Gigabit switch, delivering a simplified, cost-effective networking solution.

Figure 1 shows the front panel of AC6508.

Quick Spacs

Parameter	Specification
Model	AC6508
Ports	10 x GE RJ45, 2 x 10GE SFP+
Max Managed APs	512
Forwarding Capacity	10 Gbps
Max Users	4,096
Power	AC/DC Adapter (25.06W)华为
Dimensions	43.6 x 250 x 210 mm
Weight	1.9 kg

Huawei AC6508 Specification

Hardware	Details
Form Factor	Desktop/Wall-mount/Rack-mount
Interfaces	10 x GE electrical, 2 x 10GE SFP+ optical
Management	1 x Console, 1 x MGMT, 1 x USB 2.0
Memory	Flash: 1GB
Power Input	100~240V AC, 12V DC
Max Power	25.06W
Heat Dissipation	Fanless, 85.50 BTU/hour
Operating Temp	0°C ~ 45°C
Performance
AP Capacity	Up to 512 APs
User Capacity	Up to 4,096 concurrent users
Throughput	10 Gbps switching capacity
Protocols & Features
Wi-Fi Standards	802.11a/b/g/n/ac/ax/be
Networking Modes	Inline, Bypass, Bridge, Mesh
Forwarding Modes	Local (Direct) & Centralized (Tunnel)
Security	Portal/802.1X Auth, ACL, WPA2/WPA3
High Availability	1+1 Hot Standby (HSB)
Management
Interfaces	Web UI, CLI, eSight, SNMP
