24 Ethernet Huawei Network Switches S5720-28X-PWR-SI-DC 10/100/1000 PoE+ Ports 4 10 Gig SFP+
Huawei Swtich S5720-28X-PWR-SI-DC 24 Ethernet 10/100/1000 PoE+ ports 4 10 Gig SFP+
S5720-28X-PWR-SI-DC Overview
Huawei S5720-28X-PWR-SI-DC is one of the S5720-SI switches.The S5720-SI series switches (S5720-SI for short) are next-generation standard gigabit Layer 3 Ethernet switches based on a new generation of high-performance hardware and Huawei Versatile Routing Platform (VRP). They provide large switching capacity and high-density GE and 10 GE uplink interfaces. With extensive service features and IPv6 forwarding capabilities, the S5720-SI can be used as access or aggregation switches on campus networks or access switches in data centers. The S5720-SI series integrates many advanced technologies in terms of reliability, security, and energy savings. Simple and convenient to install and maintain, reducing customers’ O&M costs and helping enterprise customers build next-generation IT networks.
S5720-28X-PWR-SI-DC Specification
S5720-28X-PWR-SI-DC Specifications |
|
| Switching Capacity | 336 Gbit/s |
| Forwarding Performance | 42 Mpps/57 Mpps/78 Mpps/96 Mpps/132 Mpps |
| Fixed Ports |
24 Ethernet 10/100/1,000 ports, 4 of which are dual-purpose 10/100/1,000 or SFP P series: 4 Gig SFP X series: 4 x 10 Gig SFP+ |
| MAC Address Table | 16K |
| Ring Protection |
RRPP ring topology and RRPP multi-instance Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level protection switchover SEP ERPS (G.8032) STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s) BPDU protection, root protection, and loop protection |
| IP Routing | Static route, RIPv1, RIPv2, RIPng, ECMP, OSPF, OSPFv3, BGP, BGP4+, IS-IS, IS-ISv6, VRRP, and VRRP6 |
| Multicast |
PIM-DM, PIM-SM, and PIM-SSM IGMP v1/v2/v3 snooping and IGMP fast leave Multicast forwarding in a VLAN and multicast replication between VLANs Multicast load balancing among member ports of a trunk Controllable multicast Port-based multicast traffic statistics |
| Security |
User privilege management and password protection DoS attack defense, ARP attack defense, and ICMP attack defense Binding of the IP address, MAC address, interface, and VLAN Port isolation, port security, and sticky MAC Blackhole MAC address entries MAC Forced Forwarding (MFF) Limit on the number of learned MAC addresses 802.1x authentication and limit on the number of users on an interface AAA authentication, RADIUS authentication, HWTACACS+ authentication, and NAC SSH v2.0 Hypertext Transfer Protocol Secure (HTTPS) CPU defense Blacklist and whitelist 802.1x authentication, MAC address authentication, and combined authentication on a per port basis Portal authentication on a per VLANIF interface basis MACSec (hardware ready) |
| Super Virtual Fabric (SVF) |
Working as an SVF client that is plug-and-play with zero configuration Automatically loading the system software package and client patches One-click and automatic delivery of service configurations Supports independent running client |
| Management and Maintenance |
iStack Virtual cable test SNMP v1/v2c/v3 RMON Web-based NMS System logs and alarms of different levels sFlow |
| Interoperability |
VLAN-based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST) Link-type Negotiation Protocol (LNP) (similar to DTP) VLAN Central Management Protocol (VCMP) (similar to VTP) |
