Steel Mill Electrical 50t Railway Transfer Cart
Steel Mill Electrical 50t Railway Transfer Cart
Product Introduction
Our rail transfer cart, also known as industrial transfer vehicles or electric flatbed trolley, can meet heavy loads with a capacity of up to 1500 tons. The electric transfer cart has a perfect combination of stable cast steel wheels, powerful motor, transformer, electrical box, carbon brush and conductive column.
Customization is our strength, we will design the perfect flat cart according to your specific requirements. Whether it is load capacity, body color, or table size, we provide customized services for you.
Electric transfer cart are widely used in factories, construction sites, aviation, ports, warehouses and so on. We design electric transport carts that are not only easy to operate, but also provide a reliable and efficient solution for transporting heavy goods within the factory.
Product Details
Advantages
Parameter List
|
Model
|
KPD-2T | KPD-5T | KPD-10T | KPD-20T | KPD-30T | KPD-40T | KPD-50T | KPD-63T | |
| Rated load (T) | 2 | 5 | 10 | 20 | 30 | 40 | 50 | 63 | |
| Table size | length(L) | 2000 | 3500 | 3600 | 4000 | 4500 | 5000 | 5500 | 5600 |
| Width(W) | 1500 | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2500 | |
| Height(H) | 450 | 450 | 500 | 550 | 600 | 650 | 650 | 750 | |
| Wheel Base (mm) | 1200 | 2500 | 2600 | 2800 | 3200 | 3800 | 4200 | 4300 | |
| Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | |
| Wheel Diameter(mm) | Φ270 | Φ300 | Φ300 | Φ350 | Φ400 | Φ500 | Φ500 | Φ600 | |
| Wheel Quantity(Nos) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | |
| Running speed (m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | |
| Motor Power (Kw) | 1 | 1.2 | 1.6 | 2.2 | 3.5 | 4 | 5 | 6.3 | |
| Transformer Power (KVA) | 3 | 5 | 5 | 6.8 | 10 | 10 | 10 | 20 | |
| Transformer Quantity (Pcs) | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
| Running Distance (m) | 80 | 80 | 80 | 80 | 80 | 60 | 50 | 50 | |
| Max Wheel Load (KN) | 14.4 | 25.8 | 42.6 | 77.7 | 110.4 | 142.8 | 174 | 221.4 | |
| Reference Weight (T) | 2.8 | 3.6 | 4.2 | 5.9 | 6.8 | 7.6 | 8 | 10.8 | |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P38 | P43 | P43 | P50 | |
Application
Shipping
About Us
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
