Steel Silver Dual Packs Air Lift Suspension Compressor Fast Inflation For Car Heavy Duty Strong Power
Steel Silver Dual Packs Air Suspension System Fast Inflation For Car Heavy Duty Strong Power
►Used with
• Air tanks in different sizes
• Pneumatic system
• Air horns
• Air spring
►Our Advantages
|
1 . One year warranty
|
2 . Competitive price among manufactures
|
|
3 . Portable to carry with
|
4. Fast inflation and low noise
|
|
5.Can be pumped more than 20 , 000 times
|
6. Water proof : Can work in the water for 2 hours , IP67
|
►SPECIFICATION
4.5 CFM 150PSI
12 Volt
Duty Cycle:33% @ 100PSI
Max Working Pressure :150PSI
Max Amp Draw: 60Amps
1/4”NPT Inlet port
Net Weight:16.4lbs
P/N 9.45”Lx4”Wx6.85”H
►PARTS INCLUDED
(2)YF6470R Compressors
(2)Air Filter Assemblies
(2)Leader Hose Clips
(2)Remote Mount Brackets
(2)Sets of Remote Mount Fittings
(2)Air Line Clips with Included Hardware
(2)Sets of Nuts Bolts Washers and Lock Washers
(2)Heavy Duty 60Amp Relays
(1)One Heavy Duty Pressure Switch(110psi on, 145psi off)
Air Line(For Remote Mount Filter Installation)
►PERFORMANCE DATA
| PSI | 0 | 40 | 90 | 150 |
| AMPS | 36 | 46 | 52 | 48 |
| CFM | 4.5 | 3.4 | 2.6 | 1.6 |
| LPM | 128 | 96 | 73 | 48 |
| BAR | 0 | 3 | 6 | 10 |
► RECOMMENDED TANK
TANK FILL DATA
2.5 Gallon Tank
0 to 150 psi 1 min 12 sec
120 to 150 psi 22 sec
5.0 Gallon Tank
0 to 150 psi 2 min 31 sec
120 to 150 psi 46 sec
