Charmhigh Table top SMT Pick and Place Machine 4 Heads 50 Feeders High-end

Charmhigh CHM-650 Advanced SMT Pick and Place Machine 4 Heads 50 Feeders


CHM-650 Main features:

1. Model number: CHM-650

2. Brand: Charmhigh

3. Main configuration: Desktop type + PCB auto delivery + 4 Heads 50 feeders + Panasonic servo motor + auto nozzle changer + Ball screw + linear guide rail + 7 cameras + updated smart software

4. Feeder: 2 options: Yamaha electric feeder / pneumatic feeder (feeders purchase separately)

5. Max PCB area: 400*350mm ; Max component height : 12mm

6. Comes with computer & keyboard & mouse with Windows system

7. Component: 0201, 0402-5050, SOP, QFN, TQFP, BGA... etc.

8. Dimension: 1280(L)*1190(W)*1050(H)mm, AC220V (50/60Hz)

9. Lead time: 3-5 working days

10. Delivery: by train/ by air / by sea / pick up from our factory directly / send to China warehouse

11. Payment method: wire transfer (T/T)

12. Packing: plywood box

YouTube working video:

CHM-650 mounting 0201 0402 TQFP 128pin:
https://youtu.be/PdjjR7lc56Q

CHM-650 mix mounting:
https://www.youtube.com/watch?v=Hk0rwxEVXf8

CHM-650 working video from Bulgarian customer:
https://www.youtube.com/watch?v=50mu2rlPrrc

Real shot of CHM-650 4 heads pick and place robot at factory:
https://www.youtube.com/watch?v=R6UZqwV8Zvc

Feature of CHM-650 SMT Mounting Machine

• The operation is simple and easy to understand with Chinese operation interface.
• Equipped with CCD positioning system, automatic vision positioning compensation, correction of board advance deviation.
• The super-size carrying track is suitable for PCB boards of various sizes.
• The non-contact high-speed injection valve realizes the continuous movement of the dispensing head and high efficiency.
• The use of injection valves brings high reliability and consistency of dispensing, as well as high productivity and material utilization
• Real-time monitoring of glue quantity, automatic prompt for low glue quantity
• Configure an industrial control system with a large-capacity high-speed SSD, high-speed access to ensure system response speed

Each side 25pcs feeders, total 50pcs tape feeders supported:​  (Yamaha electric feeder + pneumatic both suitable)

8/12/16/24/32/44mm feeder, stick feeder, IC tray supported, these parts need to be purcahsed separately.

4 heads with Samsung Nozzles:



Please note:
The pick and place machine is complete set with all accessories included in the package.

You need to purchase feeders separately and need to prepare compressor with 10mm outer diameter pipe (supplying air for feeders, ANC, PCB stopper...)

Inserting the pipe on the backside of machine.
Please purchase this machine with confidence. Enjoy with your pick and place machine!

Service & Warranty:
The complete machine has a warranty period of 1 year from the time of purchase and lifetime service.
We always provide spare parts of machines, factory reliable direct supply.
We provide online Q/A and troubleshooting support and technical advice service.
Provide one to one after-sale service. Each machine 100% tested well before shipping out.
