AAC 7mm / 4.75mm MOON AS 1531 Standard OEM For OLEX Overhead Bare Conductor

Price Negotiable

Price: USD 0.08-6.32/M

MOQ: 500m

Delivery Time: 7 Days

Brand: SHAN CABLE

Product Description

AAC 7/4.75mm MOON AS 1531 Standard OEM For OLEX Overhead Bare Conductor Which is used for Aerial Power Network

TECHNICAL SPECIFICATION AND PACKING DETAIL

(MOON)

Description: Overhead AAC conductor which is used for aerial power networks is suitable for aerial installation between poles.

Construction: The metallic conductor (AAC) is consisted of hard-drawn aluminum wires.

Standard: AS1531

AAC Cross section diagram

MOON

Properties of AAC 7/4.75mm

ITEM	DESCRIPTION	UNIT	TECHNICAL PARTICULARS
1	Code name	-	MOON
2	Applicable Standards	-	AS1531
3	Type of conductor	-	AAC
4	Properties of Hard-drawn Aluminum wires
	Nominal Diameter	mm	4.75
	Max.	mm	4.798
	Min.	mm	4.703
	Cross-sectional area	mm²	17.72
	Approx. Mass	Kg/km	47.8
	Minimum ultimate tensile stress	MPa	160
	Maximum DC resistance at 20℃	Ω/km	1.60
5	Properties of Stranded conductor
	Stranding and wire diameter: Aluminum wire		7/4.75
	Lay length of outermost layer		178(-0,+7)
	Lay direction of outermost layer		Right hand
	Approx. Overall diameter	mm	14.3
	Cross-sectional area	mm²	124.0
	Approx. mass(without grease)	Kg/km	339
	Minimum breaking load	kN	18.9
	Maximum DC resistance at 20℃	Ω/km	0.232

Some not mentioned, please see AS1531.

PACKING DETAIL

Conductors shall be wound on a non-returnable fumigated drum or metal drum. The

required marking shall be printed with a weather-proof material on the outsides of drum

according to customer’s requirement.

Cable Type	Drum Length	Drum Dimensions & Weights						Material
	Drum Length	D	d	B	b	A	Net Weight
	m	mm	mm	mm	mm	mm	kg
MOON 7/4.75	2200	1250	600	720	630	95	746	Fumigated wooden drum
Note: 1 The value"D" don't contain the dimension of seal. 2 The approximate weight of drum(Φ1250) is 150 kilograms.
