200 liter Indirect heating all in one heat pump with pressure-free tank
| ALL IN ONE HEAT PUMP | |
| Model No. | TRT-1HP-200 |
| Water Tank Type | Pressure-Free |
| Water Tank Volume(L) | 200 |
| Power Supply | 220-240V/1N/50Hz |
| Rated Input Power(W) | 680/850 |
| Rated Heating Capacity(W) | 2800/3500 |
| Refrigerant | R134A/R417A |
| Inner Water Pipe Heating Coil | SUS316 of 25 Meters *DN15 |
| Water Inlet and Outlet Size | DN15 |
| Heating Exchanger coil | SUS316 of 25 Meters *9.52 |
| Max Storage Tank Water Temp(℃) | 75 |
| Rated Hot Water Outlet(℃) | 55 |
| Max Hot Water Outlet(℃) | 60 |
| Net Weight(KG) | 70 |
| Net Size(MM) | 560*1680 |
Product advantages:
Clean Hot Water + Long life Water Tank
1) it has two heating coils inside of water tank:
one heating coil is used for heating water in water tank, which is gas cycle heating;
the other heating coil is for hot water heating, the cold water will be circulating inside of this coil, The hot water inside of tank will heat this coils and then we will get hot water outlet, this is water cycle heating.
2) If the water quality is not good, this kind of heat pump will be best option, because the water in the water tank is stable and it is not for hot water application, it is just for heating the coil. No matter how bad the water quality will be , it will not be bad for water tank.
3) we use press-free water tank, so the water tank life is much longer than pressure-bearing type tank.
4) Using R134A refrigerant, the water tank storage water temperature can be up to 75 ℃.
