Low Potential high potential Magnesium anode with fillings AZ63
HIGH BROAD provides a variety of aluminum, magnesium, zinc and mixed metal oxide cathodic protection system anodes for corrosion protection.
1) Commodity: Marine Anode
2) Standard: ASTM-97
GB/T 17731-2004 Magnesium sacrificial anode
SY/T 0019-97 Buried steel pipeline sacrificial anode catholic protection standard
3) Packing: Zina Anodes on wooden pallet wrapped with plastic tandard exported package , suit for long time sea transports
4) Advantages and usages:
Magnesium anodes is used in the technical method of electrochemistry cathode protection. theory is from that connect with the protected metal body ,with the exhausting and dissolving of negative metal material or alloy ,protective curer body will be protected from corrosion . Mg anode can produce higher quality potential power, is ideal sacrificial materials.
Magnesium anode is used in ship equipment and building, port construction, sea project, underneath pipeline, petroleum chemical fields.
5) Electrochemical properties of cast magnesium anode
| Product item | open-circuit voltage | open-circuit voltage | acuter capacitance | Current efficiency | |
| (-v) | (-v) | (A.H/G) | (%) | ||
| Mg anode with low potential AZ63 | 1.50-1.55 | 1.45-1.50 | ≥1.105 | ≥50 | |
| Mg anode with high potential Mg-Mn | 1.70-1.75 | 1.57-1.62 | ≥1.100 | ≥50 | |
6) Electrochemical properties of extrude magnesium rod anode
| Product item | open-circuit voltage | open-circuit voltage | acuter capacitance | Current efficiency | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| (-v) | (-v) | (A.H/G) | (%) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| mg anode with low potential AZ31 | 1.50-1.55 | 1.45-1.50 | ≥1.105 | ≥50 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Mg anode with high potential Mg-Mn | 1.70-1.75 | 1.57-1.62 | ≥1.100 | ≥50 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
7) Magnesium Anode Dimensions Specificantion of “S”shaped Mg sacrificed anodes
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Specification of “D”shapde Mg sacrificed anodes
| Type | Weight Kg(Lb) | Specification of anodes Inch(mm) | |||
| A | B | C | |||
| 9D2 | 4.082(9) | 2 3/4(69.9) | 3(76.2) | 21 5/8(549.3) | |
| 14D2 | 6.350(14) | 2 3/4(69.9) | 3(76.2) | 33 1/2(850.9) | |
| 20D2 | 9.072(20) | 2 3/4(69.9) | 3(76.2) | 47 3/4(1212.9) | |
| 9D3 | 4.08(9) | 3 1/2(88.9) | 3 3/4(95.3) | 13 7/8(352.4) | |
| 17D3 | 7.711(17) | 3 1/2(88.9) | 3 3/4(95.3) | 25 1/4(641.4) | |
| 32D5 | 14.515(32) | 5 1/2(139.7) | 5 3/4(146.1) | 19 7/8(504.8) | |
| 48D5 | 21.772(48) | 5 1/2(139.7) | 5 3/4(146.1) | 30 1/8(765.2) | |
| 1.5Kg | 1.5(3.5) | 3 3/20(80.0) | 2 3/4(70.0) | 7 1/2(190.0) | |
| 2.5Kg | 2.5(5.5) | 3 3/20(80.0) | 2 3/4(70.0) | 11 4/5(300.0) | |
Specification of “C”shapde Mg sacrificed anodes
| Type | Diameter (mm) | High Potential L(mm) | AZ63 Anode L(mm) | Weight (Kg) | |
| C25 | 75 | 336 | 325 | 2.56 | |
| C36 | 114 | 202 | 193 | 3.7 | |
| C41 | 114 | 230 | 220 | 4.2 | |
| C77 | 11 | 431 | 412 | 7.8 | |
| C100 | 11 | 560 | 536 | 10.2 | |
| C145 | 146 | 494 | 472 | 14.7 | |
| C227 | 178 | 520 | 497 | 22.9 | |
| C274 | 114 | 1528 | 1462 | 28 |
The length can be changed according to clients’ requirements.
We are a professional anode supplier over 16 years ,mainly supply:
* Magnesium anodes ( ASTM-G97)
* Zinc anodes (ASTM B418-95 US MILL 18001K)
* Al-Zn-In anodes (GAIII)
* High silicon cast iron anodes ( ASTM-A518-3,BS1591)
Our anodes are shipped worldwide especial main to North America, Asia etc., around 5000mt per year. Our goods are regularly tested by independent third party lab in USA to keep anode continuous high quality. Our plant owns raw material resources ore, so we can supply very good price with service for you.
We can also accept customized anodes with your logo according to your drawing !
-Magnesium anode,anode with fillings
-High potential anode filled with fillings
-Mg grounding battery,Zinc grounding battery
Magnesium anode with fillings,cathodic protection
High potential anode filled with fillings
Mg grounding battery,Zinc grounding battery
We can manufacture the High potential anode filled with fillings,Magnesium anode series products according to customers requirement, welcome to contact us.
