AZ31 AZ91 magnesium anode rod water heater , solar water heater parts

Our standard anodes are manufactured out of high-quality extruded magnesium. They are subject to a constant quality control and are in accordance with European standard DIN EN 12438 (approved for drinking water). The standard anodes can be used for all tank sizes and types (all brands) from 30 to 20.000 litres.

Examples for standard models:

Tank size Dimension of Order Model

in litre MG-Anode

30 - 50 l D21 x 210 mm M8 bolt

30 - 50 l D26 x 130 mm M8 bolt

80 l D26 x 225 mm M8 bolt

80 l D21 x 310 mm M8 bolt

120 l D26 x 320 mm M8 bolt

150 - 200 l D21 x 500 mm M8 bolt

150 - 200 l D26 x 500 mm M8 bolt

150 - 200 l D33 x 500 mm M8 bolt

200 l D21 x 700 mm M8 bolt

200 - 300 l D33 x 700 mm M8 bolt

500 l D33 x 800 mm M8 bolt

1000 l D33 x 1000 mm M8 bolt

1500 l D33 x 1500 mm M8 bolt

1500 l D33 x 1800 mm M8 bolt

The standard anodes are available optionally with a M8 bolt, with a screw connection or adapter G ¾“, G1“, G 1 ¼“, G 1 ½“. They can be ordered as well by the metre.

All standard anodes will be delivered with nuts, seal, and washer.
