10M Galvanized tubular steel pole 110kv Voltage Painting Surface Coating
Conical 10M Galvanized Steel Tubular Metal Pole For 110kv Power Distribution Transmission Line
Specification
| Material | Q235 or Q345 or Q420 or Q460 |
| Voltage Grade | 10KV, 110KV, 220KV, 500KV,750kV,800kV,1000kV,1100kV or others |
| Height | 10M-50 M |
| Antenna Support | 3-20 PCS |
| Wind Pressure | 5-190 KM/H |
| Surface Coating | Hot Dip Galvanization or Painting |
| Welding | CO2 welding or Submerged arc auto methods |
| Spare Parts | Parts for connection or installation will be provided |
| Lifetime | More than 25 years |
| Capacity | 2500 MT per Month |
Description
The HDG Electrical Steel Tubular Pole was designed as customer's request. For Distribution and Transmission Line use. And with Base Plate use Anchor Bolts to Install. Sections with 2 and use flange to connect each segment. The hot dip galvanized in accordance with ASTM 123 and the zinc coating at least 86 microns.
But to design the practical poles for customers use, normally we need customers to provide us some parameter, like as the followings :
- Pole top design load
- Where is the position of the load, the distance from the top
- The wind Speed
- How will the wire distribute
- Pole type with Burial Type or Base Plate type
- The connections mode, use slip joint or flange
- and others can be furthermore discussed when needed.
Through the efforts of the company staff, the support and cooperation from all over the world. Baojuhe's steel poles have been exported to the Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World per day on average.
Parameter
1. Steel materials conform to ASTM A36 with Q345 (S355JR), Q460, etc
2. Welding: Welding complies with CSA and AWS, AWS D1.1 standard. The welders have got corresponding
certificate after testing and inspection.
3. Finish: Hot-dip galvanized in accordance with ASTM A123.
4. Pole Height: ＞5M
5. Pole Shape: Conical / Round
6. Type: Straight Pole, Tensile Pole, Turn Pole (Double-loop corner pole, Single or double loops/circuit pole,
single or double tensile/terminal/straight pole, etc)
7. Resistant: Against earthquake of 8.8 grade. Wind speed as design.
8. Quality Standard: ISO9001:2008, AAA credit rating, etc
9. Easy install and maintenance
10. Voltage:10-550KV
Material Test:
1. All of our materials are purchased from famous mill factory to assure the quality.
2. A mill certificate issued by the mill factory with stamp and signature must be provided before unloading the material in our factory;
3. Before putting into production, all the material must pass the chemical and physical analysis to make sure that they have met the requested strength and components.
Production Process
- Raw material test
- Cutting
- Bending
- Welding (longitudinal )
- Dimension verify
- Flange welding
- Hole drilling
- Calibration
- Deburr
- Galvanization or powder coating or Bituminous painting
- Recalibration
- Packages
|
Best Service: -- Jiangsu Baojuhe Science and Technology Co., Ltd, which always been providing |
|
Quick Lead Time.--We inform the client the exact delivery time when they place the order and work Hard to |
| Unbeatable Prices-- Raw Material Cost + Produce Cost 1200 RMB/Ton |
| Unbeatable Quality -- We always supply good quality also leading products to all of our customers. |
| Brand Awareness -- We achieve a good reputation among our clients and develop long term business. |
| Special Offers. -- We quote first and then you compare, finally choose us! |
| Special support.-- we have a policy term to support our customers for products also payment. |
Terms and Conditions
1. Price Term: EXW, FOB, CFR or CIF.
Ø EXW: Poles Cost
Ø FOB : Pole Cost + Land Transportation + Fee on Port
Ø CFR : Pole Cost + Land Transportation + Fee on Port + Sea Freight
Ø C I F : Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.
2. MOQ: One 40FT Container.
3. Payment Term: Typically 30% by T/T as a deposit, balance by T/T or L/C at sight before shipment. Other
payment way can be negotiated.
4. Delivery Time: 15 working days per container after PI/drawing/ prepayment confirmed.
5. Package: Normally wrapped by plastic bags or burlap cloth at the top and bottom, or according to clients’
requirement.
After - Sales Service
Our staff supply excellent after service, track and get the product information after our client got the products. We asked our client to fill a “Survey form for Satisfaction degree from Client”. We will solve the problems from clients in 24 hours, and we improve the quality and working method according to client’s good suggestions.
