Railway use 9m Electrical Metal Utility Pole Straight Pole 4.0mm - 10mm Wall thickness
Railway use Hot Dip Galvanized Electrical Metal Utility Steel Pole Height 9m
Specification
| Products |
|
| Type |
|
| Height |
|
| Shape |
|
| Material |
|
| Wall thickness |
|
| Once Forming | Yes |
| Welding |
|
| Joint | No |
| Base plate |
|
| Galvanization |
|
| Warranty |
|
Description
Our steel poles, being manufactured from steel sheet that has been subjected to hydraulic pressure and longitudinal welding, has a tapered tubular structure with a multilateral cross-section. To achieve a proper height, steel poles can be assembled by insert mode or flange mode at the installation site.
The hot-dip galvanization technique could protect steel pole from corrosion for as long as 50 years
As an alternative to the traditional wood and concrete poles, our hot dip galvanized steel pole could be utilized to bear the conductors and electric distribution equipment, power transmission equipment, cables, etc.
Production Process
- Raw material test
- Cutting
- Bending
- Welding (longitudinal )
- Dimension verify
- Flange welding
- Hole drilling
- Calibration
- Deburr
- Galvanization or powder coating or Bituminous painting
- Recalibration
- Packages
Through the efforts of the company staff, the support and cooperation from all over the world. The company's products have been exported to the Philippines, Malaysia, Australia, America, Africa, Latin America, Panama, Suriname, Costa Rica, Colombia, Jordan, Nigeria, etc. We have good export experience and with 1 container export to World per day on average.
Galvanization.
Our factory own 3 galvanization plants to ensure the good quality. Hot dip galvanized in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123. Zinc Coating thick min 86 microns.
Features:
1. We can supply the product based on client's required drawing, but also can supply the design for any kinds of
electric poles for customers to select.
2. Matercial : hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3
3. Deal: Hot dip galvanized Following ASTM A 123 or any other standard by client required.
4. Packing: Plastic bubble, Mat &Straw Bale or following client required
5. Length: within 14meters once forming( single section)
6. Thickness: from 2.5mm to 22mm
7. Shape: polygonal(6-side,8side,12-side,16side) round tapered.
8. Easy install and maintenance.
FAQ
How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every pole before delivered.
Guaranteed:
If products' quality doesn’t accord to descriptions as we give or the promise before you place an order, we promise 100% refund.
How about price?
we are the factory and are able to give you the lowest price below market one, and discount can be given based on quantity”.
Why choose us?
Good Quality; Low Price; Best Service!
After - Sales Service
Our staff supply excellent after service, track and get the product information after our client got the products. We asked our client to fill a “Survey form for Satisfaction degree from Client”. We will solve the problems from clients in 24 hours, and we improve the quality and working method according to client’s good suggestions.
