1/2.3" 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens

Price Negotiable
Price: Negotiable
MOQ: 100pcs
Delivery Time: 2-7 work days
Brand: CCOM LENS
Product Description

1/2.3" 4.3mm F2.8 14Megapixel s-mount low-distortion lens for scanners/HD cameras, 4.3mm 4K megapixel lens for Drones/Gopros/UAVs...



4.3mm 14MP lens for See3CAM_CU130_CHL, See3CAM_CU135 - 4K USB Camera, See3CAM_stereo, SEE3CAM_CU313, e-CAM50-CU9P031, etc.



Model: 123043MPF
Sensor: 1/2.3"
Max image circle: Ø 8.1mm
Focal length: 4.3mm
Resolution: 14MP
F/No.: 2.8
B.F.L.: 3.62mm
F.B.L.: 2.82mm
T.T.L.: 22.00mm
F.O.V: 82°(D) x 72°(H) x 56°(V)
Distortion(TV-DVST): <-1.2%
Mount: M12*P0.5
Lens Constructure: 4G2P+IR
RELATIVE ILLUMIMATION: >80%
CUT FREQUENCY AT50%: λ=650±10nm



1/2.3" 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens



1/2.3" 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens



Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional

- For more lenses, please feel free to contact us at sales01@megapixellenses.com; cctv.lens@ccom-tech.com
